Zip Tie
Secondary
Tie off Point
Figure 45.
Attaching the Secondary Support Line to the CS 26T Plus
NOTE:
Observe all applicable building codes and local ordinances when installing
the speaker.
9.
Mount the CS 26T Plus (see figure 46 below).
a.
Insert the CS 26T Plus through the bottom of the hole in the ceiling tile that was
cut in
.
step 4
b.
Tighten the four screws (clockwise) until the speaker is securely clamped to the
ceiling.
Speaker Mounted with
the CS 120P
Figure 46.
Mounting the Speaker to the CS 120P
CS 26T Plus and CS 120P User Guide • Installation
29
