Ip Phone Boot Messages - Altigen Alti-IP 600 Administration Manual

LCD Messages
REGISTERING!
REMOVE OLD EXT.

IP Phone Boot Messages

The following messages may be displayed in the LCD when booting the
Alti-IP 600:
Message
CHECK FW
CHECK MEMORY
INIT NETWORK
LOAD FAILED
NETWORK FAILED.
TFTP FAIL!
UPDATE FAILED.
UPDATE OK
update APP(S1)
40 Alti-IP 600 Administration Manual
User entered #27 to manually register the IP
extension.
When #27 is entered, the extension/password
configuration in the IP Phone is removed.
Definition
Checking firmware.
Checking memory.
Initializing network.
Failure to load the image into memory.
Network initialization failed.
Failure downloading TFTP.
Firmware update failed.
Firmware update successful.
Appears when Boot Download is set to TRUE.
The Alti-IP 600 will show this message when it is
rebooted.
