To connect the Alti-IP 600:
a. Connect an Ethernet cable from the IP-PBX to the network port on
the phone.
b. Connect the handset to the receiver jack.
c. Connect an Ethernet cable from another network device, such as a
desktop computer, to the access PC port on the phone.
d. Connect the power plug to the AC Adapter port.
4. Configuring Startup Network Settings
If you are using DHCP, you do not need to configure anything.
Proceed to Step 5.
If you are not using DHCP, you must configure these network settings
on the Alti-IP 600 after installing the phone on the network:
• Local IP address
• IP subnet mask
• Default gateway IP address
5. Configuring the AltiWare IP Settings
If you are using Gatekeeper Auto Discovery, you do not need to
configure anything. Proceed to Step 6.
If you are not using Gatekeeper Auto Discovery, you must manually
configure the AltiWare IP address setting into the Alti-IP 600. Refer to
"Configuring IP Settings" on page 24.
6. Activate the IP Extension
Once the device is initialized, the user must follow these steps to
activate the IP Extension.
Note: The user must be running AltiGen's Gatekeeper service for full
functionality.
a. With the handset onhook, press # 27, then the ENTER button.
b. Enter your extension number and password when prompted.
c. The phone will attempt to register as shown in the LCD screen.
