7. Set up IP Phone properties in AltiWare as described in Step 2 -
"AltiAdmin/ACM Admin Setup - AltiGen IP Phone Configuration
Window" on page 7.
8. Setup is complete. For further configuration of settings for the Alti-IP
600, refer to "Configuring Phone Settings" on page 21.

Remote Installation

To install the Alti-IP 600 at a remote location, using a DSL connection with
or without a router hub:
1. Check the firewall settings at the corporate network to open TCP/UDP
ports required by the Alti-IP 600. (For more information on firewall
settings, refer to "Firewall Considerations" on page 34.)
2. Check the AltiWare server's IP extension settings (make sure the IP
extension is enabled, enough IP licenses are available, etc.)
3. Press * * 7 ENTER on the Alti-IP 600 phone to configure the phone's
local IP address and Gateway IP address. (Depending on the DSL
provider's recommendations, you may or may not want to use DHCP.)
4. Configure the Alti-IP 600 phone's AltiWare address.
5. If NAT server is used, access NETWORK settings in the configuration
menu. Change ENABLE NAT setting to YES and assign the NAT
server's public IP address in the NAT Address setting.
6. If configuring with an H.323 NAT router, the NAT router can forward
IP traffic to a specified private IP address based on the destination port
in the TCP/IP or UDP packets. When an H.323 endpoint is behind the
H.323 NAT, you should set up the forwarding to a private IP address
of this H.323 endpoint.
If this H.323 endpoint is AltiWare, the NAT router must be configured
to forward to following ports to the H.323 endpoints private IP
address:
• TCP port 10032 (for phone service)
• TCP port 1720 (for H.225)
• TCP/UDP 49152 ~ N (for H.245 and RTP/RTCP); where N =
49152 + (62 * number of VoIP boards) - 1.
7. Use #27 + ENTER to initiate logging onto AltiServ.
