Press " (DOWN key) to disable DHCP.
4.

Configuring IP Settings

Use these guidelines when manually configuring the IP settings:
• Ensure the default gateway IP address in on the same subnet as the host
IP address.
• When inputting IP addresses into the Alti-IP 600, use the * key to enter
periods. For example, "209.120.12.8" would be inputted as
"209*120*12*8".

Assigning a Local IP Address

The IP address is the unique logical address identifying each host computer
on a TCP/IP network. An IP address is a 32-bit number expresses as four
decimal numbers from 0 to 255 separated by periods.
To assign an IP address, use the following steps:
1. Press * * 7 + ENTER button.
Use !/" to select Network, then press the ENTER button.
2.
3. Scroll to Local Address.
4. Press the ENTER button or#(FORWARD key).
5. Use the buttons on the dial pad to enter a new IP address, using the *
key to enter periods. Use the $(BACK key) to correct any mistakes.
6. Press the ENTER button.

Assigning a TFTP Server

The default TFTP Server is set to 0.0.0.0.
To assign the TFTP server, use the following steps:
1. Press * * 7.
Use !/" to select System, then press the ENTER button.
2.
3. Scroll to TFTP Server.
4. Press ENTER button or#(FORWARD key).
Alti-IP 600 Administration Manual 24
