Funkwerk bintec R1200 User Manual

Funkwerk bintec r1200; bintec r1200w(u); bintec r3000; bintec r3000w; bintec r3400; bintec r3800(wu) routers
Hide thumbs Also See for bintec R1200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
User's Guide
bintec R1200 / R1200w(u) / R3000 / R3000w / R3400 / R3800(wu)
WAN Partner
©
Copyright
December 12, 2006 Funkwerk Enterprise Communications GmbH
Version 2.9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the bintec R1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Funkwerk bintec R1200

Summary of Contents for Funkwerk bintec R1200

  • Page 1 User's Guide bintec R1200 / R1200w(u) / R3000 / R3000w / R3400 / R3800(wu) WAN Partner © Copyright December 12, 2006 Funkwerk Enterprise Communications GmbH Version 2.9...
  • Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.

  • Page 3: Table Of Contents

    WAN Partner Menu ........3 Submenu PPP .
  • Page 4 bintec User’s Guide WAN Partner...

  • Page 5: Wan Partner Menu

    WAN Partner Menu WAN Partner Menu The fields of the WAN P menu are described below. ARTNER R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN]: WAN Partners MyGateway Current WAN Partner Configuration Partnername Protocol State branch dormant DELETE EXIT To enable your gateway to set up connections to networks or hosts outside your LAN, you must configure the partners you want to connect to as so-called WAN partners on your gateway.
  • Page 6 Possible values for S field TATE ➜ The WAN partner configuration is made in the WAN P ADD/EDIT ARTNER menu: R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][ADD]: Configure WAN Partner MyGateway Partner Name Encapsulation Encryption none Compression none Calling Line Identification PPP >...
  • Page 7 WAN Partner Menu ➜ The WAN P ADD/EDIT menu consists of the following fields: ARTNER Field Description Partner Name Enter a name for uniquely identifying the WAN partner. In this field the first character must not be a number. Don’t use special characters or umlauts.
  • Page 8 As not all bintec devices support all protocols, please check prior to configuration the avail- ablity of the respective protocol according to the data sheet at www.funkwerk-ec.com. Encryption Defines the type of encryption that should be used for data traffic to the WAN partner. Only possible if STAC resp.
  • Page 9 (As not all bintec devices support all protocols and algorithms, please check prior to configura- tion the availablity of the respective protocol according to the data sheet at www.funkwerk- ec.com.) Calling Line Identification Indicates whether calls from this WAN partner...
  • Page 10 WAN Partner Menu Description Meaning MPPE V1 40 only Only MPPE version 1 with 40-bit key MPPE 56 MPPE version 1 and 2 with 56-bit key MPPE V2 56 MPPE version 2 with 56-bit key MPPE V2 56 (RFC 3078) MPPE version 2 with 56-bit key as per RFC 3078: required for MS clients as of Windows 2000 (MS service packs may be necessary,...
  • Page 11 WAN Partner Menu check prior to configuration the availablity of the respective protocol according to the data sheet at www.funkwerk-ec.com.) For all other possible values for E the field E is not dis- NCAPSULATION NCRYPTION played. WAN Partner bintec User’s Guide...
  • Page 12 WAN Partner Menu bintec User’s Guide WAN Partner...

  • Page 13: Submenu Ppp

    Submenu PPP Submenu PPP The PPP submenu is described below. R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][EDIT][PPP]: PPP Settings (branch) MyGateway Authentication CHAP + PAP Partner PPP ID Local PPP ID r3000w PPP Password Keepalives Link Quality Monitoring CANCEL ➜...
  • Page 14 Submenu PPP Field Description Keepalives Activates the function PPP-Keepalive for checking the reachability of the remote PPP terminal. Possible values: ■ off (default value for dialup connection) - deactivates keepalive. ■ on (default value for leased line) - activates keepalive. For the function PPP-Keepalive every three seconds a packet is sent to the remote termi- nal.
  • Page 15 Submenu PPP Description Meaning CHAP + PAP Run primarily CHAP, otherwise PAP. (default value) MS-CHAP Only run MS-CHAP version 1 (PPP-Microsoft Challenge Handshake Authentication Protocol). CHAP + PAP + MS- Run primarily CHAP, on denial the authentica- CHAP tion protocol required by the WAN partner. (MS-CHAP version 1 or 2 possible.) MS-CHAP V2 Run MS-CHAP version 2 only.
  • Page 16 Submenu PPP bintec User’s Guide WAN Partner...

  • Page 17: Submenu Advanced Settings

    Submenu Advanced Settings The fields of the A submenu are described below. DVANCED ETTINGS R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][EDIT][ADVANCED]: Advanced Settings (branch) MyGateway Callback Static Short Hold (sec) Idle for Dynamic Short Hold (%) Delay after Connection Failure (sec)
  • Page 18 Submenu Advanced Settings Static The static short hold setting determines how much time should pass between ➤➤ sending the last user data packet and clearing the connection. Enter a fixed period of time in seconds. Dynamic (only with ISDN) With the dynamic short hold setting, no fixed period of time is specified and the length of an ISDN charging unit is considered instead.
  • Page 19 Submenu Advanced Settings Static In static channel bundling, you specify right from the start how many B-channels the gateway uses for connections to the WAN partner, regardless of the amount of data transferred. The A menu consists of the following fields: DVANCED ETTINGS Field...
  • Page 20 Submenu Advanced Settings Field Description GPRS/UMTS Interface Only for L = GPRS/UMTS. AYER ROTOCOL Defines the slot for the UMTS modem card. Possible values: ■ Slot 0 Unix 8 AUX (default value): Defines slot 0 for use with a modem. ■...
  • Page 21 Submenu Advanced Settings Field Description Special Interface Types This option defines a special application of the interface. Possible values: ■ none (default value): No special type select- ■ dialin only: The interface is used for incom- ing dialup connections and for callback initi- ated from the outside.
  • Page 22 Submenu Advanced Settings Description Meaning yes (PPP negotiation) The gateway calls back after a period proposed by the Microsoft client (NT: 10 seconds, newer versions: 12 seconds) with the number with outgoing or both entered for the IRECTION WAN partner. If no number is entered, the required number can be reported by the caller in a PPP negotiation.
  • Page 23 As not all bintec de- AYER ROTOCOL vices support all protocols, please check prior to configuration the availablity of the respective protocol according to the data sheet at www.funkwerk-ec.com. Description Meaning ISDN 64 kbps For 64-kbps ISDN data connections.
  • Page 24 Submenu Advanced Settings Description Meaning PPP over L2TP (LNS Using this option, the WAN Partner is used for mode) accepting L2TP tunnels and terminating the encapsulated PPP data stream. PPP over L2TP (LAC Using this option, the WAN Partner is used to mode) encapsulate a PPP data stream into L2TP and create an L2TP tunnel to a remote LNS.

  • Page 25: Submenu Extended Interface Settings (Optional)

    As not all bintec gateways support a CardBus interface for an UMTS modem card, check the availablility of the respective interface type in the data sheet of your gateway at www.funkwerk-ec.com. Table 3-3: Selection options of L AYER ROTOCOL...
  • Page 26 Submenu Advanced Settings R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][EDIT][ADVANCED][EXTIF]: Extended Interface MyGateway Settings (branch) Optional Extended Interface Settings not configured yet! Mode Bandwidth On Demand Enabled Line Utilization Weighting equal Line Utilization Sample (sec) Gear Up Threshold Gear Down Threshold...
  • Page 27 Submenu Advanced Settings The E menu consists of the following fields: XTENDED NTERFACE ETTINGS Field Description ➜ Mode Only for WAN P ARTNER DVANCED ETTINGS ➜ = dynamic HANNEL UNDLING Defines which mode is used for BOD. Possible values: see table “Mode selection options,”...
  • Page 28 ➜ menu) ARTNER DVANCED ETTINGS See data sheet on www.funkwerk-ec.com check whether your gateway supports AO/DI. Only for M = Bandwidth On Demand Enabled / BAP, Active Mode / BAP, Passive Mode / BAP, Active and Passive Mode / BAP,...
  • Page 29 Submenu Advanced Settings Field Description Maximum Number of Dia- Only for MODE = Bandwidth On Demand lup Channels Enabled / BAP, Active Mode / BAP, Passive Mode / BAP, Active and Passive Mode / BAP, Client Active Mode / BAP, Dialup Server Mode Maximum possible number of ISDN B-channels that can be opened for this WAN partner.
  • Page 30 Submenu Advanced Settings Field Description ➜ ➜ PPPoE Service Name Only for WAN P ADD/EDIT ARTNER ➜ DVANCED ETTINGS AYER ROTOCOL PPP over Ethernet (PPPoE) This function is not supported at present. ➜ ➜ PPPoE Ethernet Interface Only for WAN P ADD/EDIT ARTNER ➜...
  • Page 31 AYER = AO/DI (=Always On/Dynamic ROTOCOL ISDN). The function AO/DI depends on the type of device. See data sheet on www.funkwerk- ec.com to check whether your gateway sup- ports it. The Bandwidth Allocation Protocol (BAP) has three different modes for negotiating a band- width change.
  • Page 32 Submenu Advanced Settings Description Meaning BAP, Active and Passive Choosing this option both negotiating partners Mode can have the active or the passive role. The negotiating partners behave as follows: ■ Call Request: One of the two partners wants to add a second B-channel. He sends a Call Request, the partner accepts it.
  • Page 33 Submenu Advanced Settings Description Meaning BAP, Dialup Client Mode (For dialup connections only) An ISP can fulfill the channel-bundling function, even if it distributes incoming calls to several BAP Dialup Server Mode gateways: an ISDN number is transmitted to the client who dials in. This number is assigned individually to each gateway on the central side, so that the calls on several channels to this number are always terminated on the same...
  • Page 34 1 is used for M AXIMUM UMBER OF IALUP HANNELS One additional BRI for dial-up connections must be available at least. See datasheet on www.funkwerk-ec.com to check with how many BRIs your gateway is equipped. bintec User’s Guide WAN Partner...
  • Page 35 Submenu Advanced Settings Description Meaning Bandwidth On Demand (For leased lines only) Active and Enables BOD. Bandwidth On Demand Bandwidth On Demand Active defines the Passive active partner. This side activates adding and dropping additional B-channels on demand. Bandwidth On Demand Passive defines the passive partner.
  • Page 36 Submenu Advanced Settings bintec User’s Guide WAN Partner...

  • Page 37: Submenu Wan Numbers

    WAN partner. Other numbers can be added via the ADD button. Existing entries can be edited by selecting the relevant list entry. R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][EDIT][WAN NUMBERS][ADD]: Add or Change MyGateway WAN Numbers (Filiale)
  • Page 38 Submenu WAN Numbers ➜ The WAN N ADD/EDIT menu consists of the following fields: UMBERS Field Description Number Number of WAN partner. Direction Defines whether N should be used for UMBER incoming or outgoing calls or for both. Possible values: ■...
  • Page 39 Submenu WAN Numbers Wildcards When entering the N , you can either enter the extension digit for digit or UMBER you can replace single numbers or groups of numbers with wildcards. N UMBER can therefore equal various extensions. You can use the following wildcards, which have different effects for incoming and outgoing calls: Meaning Example...

  • Page 40: Submenu Advanced Settings

    Submenu WAN Numbers Submenu Advanced Settings ➜ The WAN N submenu is described below. UMBERS DVANCED ETTINGS The gateway supports the use of the “Closed User Group” service feature, which you can request for your ISDN line from your telephone company. The reachability of your ISDN S0 interface is monitored and controlled by the ex- changes if this feature is selected.

  • Page 41: Submenu Ip

    ASIC ETTINGS is set to yes, the following screen is displayed (example RANSIT ETWORK addresses are used here): R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][EDIT][IP][BASIC]: IP Settings (branch) MyGateway IP Transit Network Local IP Address 192.168.100.1 Partner IP Address 192.168.100.2...
  • Page 42 Submenu IP To be able to transfer IP datagrams between two remote LANs, the gateway must know the route to the respective destination network. In this menu you can define the basic routing or generate a default route to the partner gateway. Default route All data is sent automatically to the WAN partner on a default route, if no other route matches.
  • Page 43 Submenu IP ➜ ➜ ➜ If in WAN P ADD/EDIT ARTNER DVANCED ETTINGS AYER ROTOCOL other options than PPP over PPTP are set, the B IP-S menu con- ASIC ETTINGS sists of the following fields: Field Description IP Transit Network Defines whether your gateway uses a transit network to the WAN partner.
  • Page 44 Submenu IP Field Description Default Route Only if dynamic client, no or yes is set for IP . Possible values: RANSIT ETWORK ■ yes: Route to this WAN partner is defined as default route. ■ no (default value): Route to this WAN part- ner is not defined as default route.

  • Page 45: Submenu More Routing

    Submenu IP Field Description Gateway IP Address Only if U = yes ATEWAY IP address of the gateway activated by setting to yes. ATEWAY Local PPTP VPN IP This field is displayed, if an ETH interface has Address been selected in V IP I and if U NTERFACE...
  • Page 46 The IP routes for a specific WAN Partner are listed in the WAN P ARTNER ➜ menu: OUTING R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][ADD][IP][ROUTING]: IP Routing (branch) MyGateway The flags are: U (Up), D (Dormant), B (Blocked), G (Gateway Route), I (Interface Route),...
  • Page 47 Submenu IP ➜ The M ADD/EDIT menu consists of the following fields: OUTING Field Description Route Type Type of route. Possible values: ■ Host route (default value): Route to a single host ■ Network route: Route to a network ■ Default route: The route is applied for all IP addresses and if no other suitable route is available.
  • Page 48 Submenu IP Field Description Metric The lower the value, the higher the priority of the route (possible values 0...15). The default value is 1. Table 5-3: menu fields OUTING offers the following selection options: ETWORK Description Meaning WAN without transit net- Route to a destination host or LAN that can be work reached via a WAN partner without including...
  • Page 49 ➜ Configuration is made in the Setup Tool menu WAN P ARTNER ➜ ADDEXT. OUTING R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][ADD][IP][ROUTING]: IP Routing - Extended Route MyGateway Route Type Host route Network WAN without transit network Destination IP Address...
  • Page 50 Submenu IP Field Description Destination IP Address Only for R = Host route or Network OUTE route IP address of the destination host or LAN. Netmask Only for R = Network route OUTE Netmask for D IP-A ESTINATION DDRESS Partner / Interface Only for N = WAN without transit ETWORK...
  • Page 51 Submenu IP Field Description Source Port Only for P = tcp or udp ROTOCOL Source port number or range of source port numbers. Destination Port Only for P = tcp or udp ROTOCOL Destination port number or range of destination port numbers.

  • Page 52: Submenu Advanced Settings

    D OURCE ESTINATION Submenu Advanced Settings The fields of the A submenu are described below. DVANCED ETTINGS R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][EDIT][IP][ADVANCED]: Advanced Settings MyGateway (branch) RIP Send none RIP Receive none IP Accounting Back Route Verify...
  • Page 53 Submenu IP ➤➤ Gateways use to exchange information stored in routing tables by communicating with each other at regular intervals. The gateway supports both version 1 and version 2 of RIP, either individually or together. RIP is configured separately for LAN and WAN. Active and passive Gateways can be defined as active or passive gateways: Active gateways offer ➤➤...
  • Page 54 Submenu IP up a connection to another host in the LAN or to a WAN partner, but doesn’t know its hardware address (MAC address), it sends an ARP request as a ➤➤ broadcast to the network. If Proxy ARP is activated on the gateway and the desired target host can be reached e.g.
  • Page 55 Submenu IP Field Description Route Announce Possible values: ■ up or dormant (default value): Routes are propagated if the interface’s status is up or dormant. ■ always: Routes are always propagated in- dependent of operational status. ■ up only: Routes are only propagated if the interface status is up.
  • Page 56 Submenu IP RIP S and RIP R contain the following selection options: ECEIVE Description Meaning none (default value) Not activated. RIP V2 multicast Only for RIP S The gateway waits for version 2 RIP packets with RIP V2 multicast address 224.0.0.9. RIP V1 triggered RIP V1 messages are sent rsp.
  • Page 57 Submenu IP Description Meaning on (up only) The gateway answers an ARP request only if the status of the connection to the WAN partner is up (active), i.e. a connection already exists to the WAN partner. Table 5-10: ARP selection options ROXY contains the following selection options: YNAMIC...
  • Page 58 Submenu IP bintec User’s Guide WAN Partner...

  • Page 59: Submenu Bridge

    Submenu Bridge Submenu Bridge The B submenu is described below. RIDGE R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WAN][ADD][BRIDGE]: Bridge Configuration (branch) MyGateway Enable Bridging CANCEL The gateway can be operated in Bridging Mode. ➤➤ ➤➤ In contrast to a...
  • Page 60 Submenu Bridge bintec User’s Guide WAN Partner...

  • Page 61: Index: Wan Partner

    Index: WAN Partner Advanced settings Authentication Authentication negotiation Back Route Verification Back Route Verify Bandwidth on Demand (BoD) Basic IP settings Bridge Bridging Mode 15, 17, 19 Callback Calling Line Identification 16, 18 Channel bundling Closed User Group 6, 7 Compression CUG index D-channel queue length...
  • Page 62 Flags Gateway IP Address Gateway IP address Gear down threshold Gear up threshold GPRS/UMTS Interface Idle for dynamic short hold (%) 51, 52 IP accounting IP transit network ISDN ports to use Keepalives 16, 17, 21 Layer 1 protocol Line utilization sample (sec) Line utilization weighting Link Quality Monitoring Local IP address...
  • Page 63 Partner PPP ID PPP password PPPoE Ethernet Interface PPPoE Service Name PPTP VPN Partner’s IP Address 3, 48 Protocol 51, 53, 54 Proxy ARP Remote IP address Remote netmask 52, 54 RIP receive 52, 54 RIP send Route 51, 53 Route announce 45, 47 Route type...
  • Page 64 Van Jacobson Header Compression via IP Interface WAN partner numbers bintec User’s Guide WAN Partner...
