User's Guide

bintec R1200 / R1200w(u) / R3000 / R3000w / R3400 / R3800(wu)

Wireless LAN

December 13, 2006 Funkwerk Enterprise Communications GmbH

Version 3.0

Table of Contents

Need help?

Do you have a question about the BINTEC R1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Funkwerk BINTEC R1200

Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
Page 3: Table Of Contents
Wireless LAN Menu ........3 Wireless Interfaces Submenu .
Page 4 bintec User’s Guide Wireless LAN...
Page 5: Wireless Lan Menu
Wireless LAN Menu Wireless LAN Menu The fields of the W LAN menu are described below. IRELESS R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0]: Configure WLAN Interface MyGateway Operation Mode Location Germany Radio Band 2,4 GHz Channel auto Wireless Interfaces >...
Page 6 Wireless LAN Menu IEEE 802.11g is presently the primarily used standard for radio-based LANs and offers a maximum data transfer rate of 54 Mbps. This method operates at a frequency of 2,4 GHz (2400 MHz - 2485 MHz), which guarantees that build- ings are penetrated with the required transmitting power that, however, does not affect health.
Page 7 Wireless LAN Menu Field Description Radio band Frequency range the access point is to operate Possible values: ■ 2,4 GHz (default value) ■ 5 GHz Usage area Only for R = 5 GHz ADIO BAND Installation location of the access point. Possible values: ■...
Page 8 Wireless LAN Menu ■ WDS L ONFIGURATION only for R = 2,4 GHz ADIO BAND ■ DVANCED bintec User’s Guide Wireless LAN...
Page 9: Wireless Interfaces Submenu
Wireless Interfaces Submenu Wireless Interfaces Submenu The fields of the W menu are described below. IRELESS NTERACES R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WIRELESS]: Interface List MyGateway Network Name Status Security ACL-Filter ifc Cl.# ----------------------------------------------------------------- *Funkwerk-ec enable NONE disable...
Page 10 (Appropri- IRELESS IRELESS NTERFACES ate WLAN settings are to be done on the WLAN Clients): ■ Change the default SSID, N = Funkwerk-ec, of your access ETWORK point. ■ ➜ Set W = no. Thus all WLAN clients are...
Page 11 14). ➜ The generation of new wireless interfaces is carried out in W IRELESS ➜ ADD: IRELESS NTERFACES R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WIRELESS][ADD]: Wireless Interface MyGateway AdminStatus enable Network Name Name is visible Max. Clients Security Mode...
Page 12 Wireless Interfaces Submenu R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WIRELESS][EDIT]: Wireless Interface MyGateway AdminStatus enable Network Name Funkwerk-ec Name is visible Max. Clients Security Mode NONE ACL Filter > IP and Bridging > SAVE CANCEL ➜ The W menu consists of the following...
Page 13 Wireless Interfaces Submenu Field Description Max. Clients Maximum number of WLAN client connections allowed for this interface. All in all 64 connec- tions can be distributed to all wireless inter- faces. Security Mode Here you select the security mode (encryption and authentication) of the wireless interface.
Page 14 WEP mode. Confirming with the input key transforms the ASCII based input into a hexadecimal phrase. For WEP40 the phrase must have 5 characters, for WEP104 13 characters. E.g. hallo for WEP40 funkwerk-wep1 for WEP104. bintec User’s Guide Wireless LAN...
Page 15 Wireless Interfaces Submenu Field Description Enter Preshared Key Only for S = WPA PSK ECURITY Here you enter the WPA passphrase. Enter an ASCII String of 8 - 63 characters. WPA/WPA2 mixed mode Only for S = WPA PSK and ECURITY WPA (802.1x) Here you select whether to apply WPA (with...
Page 16: Acl Filter Submenu
Wireless Interfaces Submenu ACL Filter Submenu The fields of the ACL F submenu are described below. ILTER R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WIRELESS][EDIT][ACCESS LIST]: Interface MyGateway <Funkwerk-ec> AdminStatus disable Accept Address ACCEPT REJECT ---------------------- ---------------------- Press 'a' to move selected Reject Address to Accept List.
Page 17: Ip And Bridging Submenu
Wireless Interfaces Submenu With the REMOVE button selected addresses can be deleted from the ACCEPT list. Removing an address from the ACCEPT list immediately disconnects an es- tablished link. The menu consists of the following fields: Field Description AdminStatus Enable or disable the filter for this wireless interface.
Page 18 Wireless Interfaces Submenu R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WIRELESS][EDIT][IP CONFIGURATION]: WLAN VSS MyGateway Interface <Funkwerk-ec> Local Communication disabled Local IP Address Local Netmask Second Local IP Address Second Local Netmask Bridging enable Proxy ARP SAVE CANCEL ➜ ➜...
Page 19 Wireless Interfaces Submenu Field Description Second Local IP Address Here you assign a second IP address to the wireless interface. Second Local Netmask Netmask for S IP N ECOND OCAL UMBER Bridging enable Enables activating the Bridging mode. Possible values: ■...
Page 20 Wireless Interfaces Submenu bintec User’s Guide Wireless LAN...
Page 21: Wds Link Configuration Submenu
WDS Link Configuration Submenu WDS Link Configuration Submenu The fields of the WDS L menu are described below. (The ONFIGURATION screenshot shows example values.) R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WDS LINK]: WDS List MyGateway MAC Address Local-IP Remote-IP Network/Mask Ena.
Page 22 WDS Link Configuration Submenu WDS link is configured as transfer network: it is a point-to-point or a point-to- multipoint connection between two gateways serving different networks. The list contains the following descriptions Column Content MAC Address MAC address of the WDS interface of the remote network.
Page 23 WDS Link Configuration Submenu R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][WDS LINK][ADD]: WDS Link MyGateway AdminStatus enable Mode transient routing Remote WDS MAC Address Local IP-Address Partner IP-Address Remote Network Remote Netmask SAVE CANCEL The menu consists of the following fields:...
Page 24 WDS Link Configuration Submenu Field Description Remote WDS MAC MAC address of the WDS interface of the Address remote network. Local IP-Address Only for M = routing or transient routing IP address of the local WDS interface. Local Netmask Only for M = routing Netmask for IP-A DDRESS...
Page 25: Advanced
Advanced Advanced The fields of the A menu are described below. DVANCED R3000w Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-8-0][ADVANCED]: WLAN Specific Settings MyGateway Wireless Mode 802.11 mixed Maximum Bitrate AUTO NITRO Burst TX Power (dBm) Timeout (minutes) SAVE CANCEL ➜...
Page 26 Advanced The menu consists of the following fields: Field Description ➜ Wireless Mode Only for W IRELESS ADIO 2,4 GHz Operating mode of the AP. Possible values: ■ 802.11 mixed (default value): for 11 Mbit and 54 Mbit Clients (for normal operation) ■...
Page 27 Advanced Field Description NITRO Burst This feature increases the maximum burst time for the transmission to a connected station, thus increasing the throughout in slower WLANs. Several WLAN data packets are sent consecu- tively ("Burst"). The necessary CTS packet for administration is only required once.
Page 28 Advanced bintec User’s Guide Wireless LAN...
Page 29: Index: Wireless Lan
Index: Wireless LAN Numerics 802.11 b/g mixed Accept Address Access Point ACL Filter Active Probing 10, 15, 21 AdminStatus Bridging enable Channel Default Key Ena. Enter Preshared Key local communication Local IP Local IP-Address local IP-Number Local Netmask local Netmask Location MAC Address Max.
Page 30 Network Name Network/Mask NITRO Burst Operation Mode Partner IP-Address Proxy ARP Radio band Remote IP Remote Netmask Remote Network Remote WDS MAC Address Second Local IP-Number Second Local Netmask Security Mode SSID Timeout (minutes) TX Power (dBm) Usage area Wireless Mode WPA/WPA2 mixed mode WPA2 preauthentication bintec User’s Guide...
