- Page 1 User’s Guide bintec R230a / R230aw / R232b / R232bw L2TP © Copyright April 20, 2006 Funkwerk Enterprise Communications GmbH Version 2.0...
- Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
- Page 3 L2TP Menu ..........3 Static settings Submenu .
- Page 4 bintec User’s Guide L2TP...
-
Page 5: L2Tp Menu
L2TP Menu L2TP Menu The fields of the L2TP menu are described below. R232bw Setup Tool Funkwerk Enterprise Communications GmbH [L2TP]: L2TP Configuration MyGateway Static settings Tunnel profiles EXIT The Layer 2 Tunneling Protocol allows tunneling PPP connections through a UDP connection. - Page 6 L2TP Menu bintec User’s Guide L2TP...
-
Page 7: Static Settings Submenu
Static settings Submenu Static settings Submenu The fields of the S menu are described below. TATIC SETTINGS R232bw Setup Tool Funkwerk Enterprise Communications GmbH [L2TP][STATIC]: L2TP Static Settings MyGateway UDP port number for LNS mode 1701 Port usage for LNS mode... - Page 8 Static settings Submenu bintec User’s Guide L2TP...
-
Page 9: Tunnel Profiles Submenu
UNNEL PROFILES nel profiles for L2TP connections. R232bw Setup Tool Funkwerk Enterprise Communications GmbH [L2TP][TUNNEL PROFILES]: Configure L2TP tunnels MyGateway Prfl Name Main Rem IP Add Rem port Rem Hostnm Loc Hostnm Password l2tp1 80.80.80.80... - Page 10 Tunnel profiles Submenu R232bw Setup Tool Funkwerk Enterprise Communications GmbH [L2TP][TUNNEL PROFILES][ADD]: Configure L2TP tunnels MyGateway Profile Name l2tp1 Local IP Address Local UDP Port (LAC only) Local Hostname Remote IP addresses through Radius (LAC only) disabled Remote IP Address - main (LAC only)
- Page 11 Tunnel profiles Submenu Field Description Local IP Address Here you enter the IP address that will be used as source address for all L2TP connections based on this profile. If left blank, the gateway uses the IP address of the interface via which the L2TP tunnel reaches R IP A EMOTE...
- Page 12 Tunnel profiles Submenu Field Description Remote IP addresses Here you define whether to use RADIUS to through Radius (LAC request R IP A and R EMOTE DDRESS MAIN EMOTE only) IP A (enabled) or not (dis- DDRESS ACKUP abled, default value). Remote IP Address (LAC Only for R EMOTE...
- Page 13 Tunnel profiles Submenu Field Description Remote Hostname Here you enter the host name of the LNS resp. LAC: ■ LAC: Defines the Local Hostname of the LNS (included in the SCCRQs received by the LNS and SCCRPs received by the LAC).
- Page 14 Tunnel profiles Submenu Field Description Hello Interval Here you enter the interval (in seconds) between sending two L2TP HELLO messages in order to keep the tunnel open. Available values are 0 to 255, the default value is 30. A value of 0 means that no L2TP HELLO messages are sent.
- Page 15 Tunnel profiles Submenu Field Description Maximum Retry Count Here you enter the maximum number of times the gateway retransmits an L2TP control packet it has not received an acknowledgement for. If this number is reached without receiving a reply, the tunnel times out. Available values are 1 to 255, the default value is 5.
- Page 16 Tunnel profiles Submenu bintec User’s Guide L2TP...
-
Page 17: Index: L2Tp
Index: L2TP Data Packets Sequence Numbers Hello Interval 3, 8 Layer 2 Tunneling Protocol 3, 5, 8 Local Hostname Local IP Address Local UDP Port (LAC only) Maximum Retry Count Maximum Time Between Retries Minimum Time Between Retries Port usage for LNS mode PPP over L2TP (LAC mode) PPP over L2TP (LNS mode) Profile Name... - Page 18 bintec User’s Guide L2TP...
