  • Page 1: Technical Data

    User’s Guide bintec R230a / R230aw / R232b / R232bw Technical Data © Copyright May 3, 2006 Funkwerk Enterprise Communications GmbH Version 2.0...
  • Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.

  • Page 3: Table Of Contents

    R230a ........
  • Page 4 3.5.2 Ethernet Interface ........24 3.5.3 ADSL Interface .

  • Page 5: Bintec R230A

    Delivery size bintec R230a All products of the R Series provide you with a similar set of functions and differ in terms of the supported interfaces or connection types. Delivery size Your gateway is supplied with the following parts: ■...

  • Page 6: Leds

    R230a Feature Data Dimensions/weight (B x H x D): Dimensions without cables 158 mm x 25,7 mm x 123.1 mm Weight approx. 550 g Transport weight (incl. documenta- approx. 1.2 kg tion, cabling, packaging) Memory 32 MB SDRAM, 8 MB Flash-ROM...

  • Page 7: Leds

    R Series Gateway indicate the states and the activity of the gateway. They are arranged as follows: Figure 1-1: LEDs on bintec R230a In operational mode the LEDs display the following status information: Status Information Power Power supply has been connected.

  • Page 8: Connections

    R230a Status Information Status The gateway is booting. flashing The gateway is active. 1 to 4 The gateway is connected to the Ethernet (100 Mbit/s or 10 Mbit/s respectively). flashing Data traffic via the Ethernet interface (100 Mbit/s or 10 Mbit/s respectively).

  • Page 9: Pin Assignments

    Pin Assignments Pin Assignments 1.5.1 Serial Interface For connecting a console bintec R230a provides a serial interface. Baud rates between 1200 and 115200 Bit/s are supported. The interface is connected through a 5-pole MiniUSB socket: Figure 1-3: 5-pole MiniUSB socket...

  • Page 10: Adsl Interface

    R230a An RJ45 socket is used for connecting: Figure 1-4: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment Function TD + TD - RD + Not used Not used RD - Not used Not used...
  • Page 11 Pin Assignments Only the inner pins are used for the ADSL connection: Figure 1-5: ADSL interface (RJ11) The ADSL interface has the following pin assignment: Function Not used Not used Table 1-5: ADSL interface (RJ11 socket) Technical Data bintec User’s Guide...
  • Page 12 R230a bintec User’s Guide Technical Data...
  • Page 13 – Serial cable – DSL cable – Power supply ■ Antennas: – two standard antennas ■ Funkwerk Companion CD ■ Documentation: – Quick Install Guide (printed) – User’s Guide (on CD) – Release Notes, if required – Safety Instructions General Product Features The general product features cover performance features and the techni- cal requirements for installation and operation of your gateway.
  • Page 14 bintec R230aw These features are outlined in the following table: Feature Data Product name bintec R230aw Dimensions/weight (B x H x D): Dimensions without cables 158 mm x 25,7 mm x 123.1 mm Weight approx. 550 g Transport weight (incl. documenta- approx.
  • Page 15 General Product Features Feature Data Available interfaces: ADSL interface Built-in ADSL modem for Annex A Serial interface V.24 Built-in, supports the following baud rates: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bauds Built-in (twisted-pair only), Ethernet IEEE 802.3 LAN 10/100 Mbps, auto sensing, MDIX (4 port switch) WLAN interface (antennas)
  • Page 16 bintec R230aw Antenna Diversity The two antennas do not have equal funtion. The one named "Main", "Primary" Note or "1" (at R Series devices the antenna next to the power switch) is used for sending and receiving, the other one only for receiving. The AP (Access point) verifies, which of the two antennas receives the better signal, which is then used for decoding.

  • Page 17: Connections

    Connections Status Information ADSL ADSL connection is active. Table 2-2: LED status display Connections All connections are located on the rear of the gateway. bintec R230aw fers a 4-port Ethernet switch, an ADSL interface as well as a serial inter- face.
  • Page 18 bintec R230aw Pin Assignments 2.5.1 Serial Interface For connecting a console bintec R230aw provides a serial interface. Baud rates between 1200 and 115200 Bit/s are supported. The interface is connected through a 5-pole MiniUSB socket: Figure 2-3: 5-pole MiniUSB socket The pin assignment of the socket is as follows: Function not used...
  • Page 19 Pin Assignments An RJ45 socket is used for connecting: Figure 2-4: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment Function TD + TD - RD + Not used Not used RD - Not used Not used Table 2-4: RJ45 socket for LAN connections The Ethernet sockets are not equipped with Auto-MDIX technology.
  • Page 20 bintec R230aw Only the inner pins are used for the ADSL connection: Figure 2-5: ADSL interface (RJ11) The ADSL interface has the following pin assignment: Function Not used Not used Table 2-5: ADSL interface (RJ11 socket) bintec User’s Guide Technical Data...
  • Page 21 – Ethernet cable – ISDN cable – Serial cable – DSL cable – Power supply ■ Funkwerk Companion CD ■ Documentation: – Quick Install Guide (printed) – User’s Guide (on CD) – Release Notes, if required – Safety Instructions General Product Features The general product features cover performance features and the techni- cal requirements for installation and operation of your gateway.
  • Page 22 bintec R232b Feature Data Dimensions/weight (B x H x D): Dimensions without cables 189.2 mm x 27 mm x 123.1 mm Weight approx. 550 g Transport weight (incl. documenta- approx. 1.2 kg tion, cabling, packaging) Memory 32 MB SDRAM, 8 MB Flash-ROM LEDs 13 (1x Power, 1x Status, 4x2 Ethernet, 1x ETH, 1x ADSL, 1x ISDN)
  • Page 23 LEDs Feature Data Plugs used: Serial interface 3-pole MiniUSB Ethernet interface RJ45 ISDN interface RJ45 ADSL interface RJ11 Community Passwords, PAP, CHAP, SAFERNET Security Technol- MS-CHAP, MS-CHAP v.2, PPTP, PPPoE, PPPoA, Access Control Lists, NAT, SIF, MPPE Encryption, VPN with IPSec Software includes BRICKware for Windows BRICKtools for Unix...

  • Page 24: Connections

    bintec R232b In operational mode the LEDs display the following status information: Status Information Power Power supply has been connected. Status The gateway is booting. flashing The gateway is active. 1 to 4 The gateway is connected to the Ethernet (100 Mbit/s or 10 Mbit/s respectively).
  • Page 25 Pin Assignments The connections are arranged as follows: 1. Reset Reset Button 5. ETH Ethernet interface Socket for power sup- 6. ADSL ADSL interface Serial interface 7. ISDN ISDN interface Console 10/100 Base-T Ether- 4/3/2/1 net interface Figure 3-2: bintec R232b rear Pin Assignments 3.5.1...
  • Page 26 bintec R232b The pin assignment of the socket is as follows: Function not used not used Table 3-3: Pin assignment of the serial socket 3.5.2 Ethernet Interface bintec R232b offers an Ethernet interface with integrated 4-port switch for LAN connection. It can be used to connect single PCs as well as addition- al switches.
  • Page 27 Pin Assignments Function TD - RD + Not used Not used RD - Not used Not used Table 3-4: RJ45 socket for LAN connections The Ethernet sockets are not equipped with Auto-MDIX technology. 3.5.3 ADSL Interface The ADSL interface is connected using a RJ11 socket. The supplied cable combines the RJ45 plug required by most ADSL splitters and the RJ11 plug required by the gateway.
  • Page 28 bintec R232b Function Not used Table 3-5: ADSL interface (RJ11 socket) 3.5.4 ISDN Basic Rate Interface bintec R232b provides an ISDN S interface, which can be used, e.g., for backup purposes. A RJ45 socket is used for connecting: 1 ..8 Figure 3-6: ISDN S interface (RJ45 socket) The ISDN interface (RJ45 socket) has the following pin assignment:...
  • Page 29 Pin Assignments Function Not used Not used Table 3-6: RJ45 socket for ISDN connection Technical Data bintec User’s Guide...
  • Page 30 bintec R232b bintec User’s Guide Technical Data...
  • Page 31 – Serial cable – DSL cable – Power supply ■ Antennas: – two standard antennas ■ Funkwerk Companion CD ■ Documentation: – Quick Install Guide (printed) – User’s Guide (on CD) – Release Notes, if required – Safety Instructions General Product Features The general product features cover performance features and the techni- cal requirements for installation and operation of your gateway.
  • Page 32 bintec R232bw These features are outlined in the following table: Feature Data Product name bintec R232bw Dimensions/weight (B x H x D): Dimensions without cables 189.2 mm x 27 mm x 123.1 mm Weight approx. 550 g Transport weight (incl. documenta- approx.
  • Page 33 General Product Features Feature Data Available interfaces: ADSL interface Built-in ADSL modem for Annex B Serial interface V.24 Built-in, supports the following baud rates: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bauds Ethernet IEEE 802.3 LAN Built-in (twisted-pair only), (4 port switch) 10/100 Mbps, auto sensing, MDIX ISDN-WAN S0...
  • Page 34 bintec R232bw Antenna Diversity The two antennas do not have equal funtion. The one named "Main", "Primary" Note or "1" (at R Series devices the antenna next to the power switch) is used for sending and receiving, the other one only for receiving. The AP (Access point) verifies, which of the two antennas receives the better signal, which is then used for decoding.
  • Page 35 Connections Status Information The gateway is connected to the Ethernet. flashing Data traffic via the Ethernet interface. ADSL ADSL connection is active. ISDN One B-channel is used. flashing Both B-channels are used. Table 4-2: LED status display Connections All connections are located on the rear of the gateway. bintec R232bw fers a 4-port Ethernet switch, an ETH interface, an ISDN interface, an ADSL interface as well as a serial interface.

  • Page 36: Pin Assignments

    bintec R232bw Pin Assignments 4.5.1 Serial Interface For connecting a console bintec R232bw provides a serial interface. Baud rates between 1200 and 115200 Bit/s are supported. The interface is connected through a 5-pole MiniUSB socket: Figure 4-3: 5-pole MiniUSB socket The pin assignment of the socket is as follows: Function not used...
  • Page 37 Pin Assignments An RJ45 socket is used for connecting: Figure 4-4: Ethernet 10/100Base-T interface (RJ45 socket) The Ethernet sockets have the following pin assignment Function TD + TD - RD + Not used Not used RD - Not used Not used Table 4-4: RJ45 socket for LAN connections The Ethernet sockets are not equipped with Auto-MDIX technology.

  • Page 38: Isdn Basic Rate Interface

    bintec R232bw Only the inner pins are used for the ADSL connection: Figure 4-5: ADSL interface (RJ11) The ADSL interface has the following pin assignment: Function Not used Not used Table 4-5: ADSL interface (RJ11 socket) 4.5.4 ISDN Basic Rate Interface bintec R232bw provides an ISDN S interface, which can be used, e.g., for...
  • Page 39 Pin Assignments The ISDN interface (RJ45 socket) has the following pin assignment: Function Not used Not used Send (+) Receive (+) Receive (-) Send (-) Not used Not used Table 4-6: RJ45 socket for ISDN connection Technical Data bintec User’s Guide...
  • Page 40 bintec R232bw bintec User’s Guide Technical Data...
