User's Guide

bintec R230a / R230aw / R232b / R232bw

Wireless LAN

April 25, 2006 Funkwerk Enterprise Communications GmbH

Version 2.0

Table of Contents

Need help?

Do you have a question about the bintec R230a and is the answer not in the manual?

Questions and answers

Summary of Contents for Funkwerk bintec R230a

Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
Page 3: Table Of Contents
Wireless LAN Menu ........3 Wireless Interface Submenu .
Page 4 bintec User’s Guide Wireless LAN...
Page 5: Wireless Lan Menu
Wireless LAN Menu Wireless LAN Menu The fields of the W LAN menu are described below. IRELESS R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0]: Configure WLAN Interface MyGateway Operation Mode Location Germany Channel Wireless Interface > Advanced > SAVE...
Page 6 Wireless LAN Menu 802.11b WLANs offer all functions of a cabled network. WLAN systems are free of charge and are not to be registered inbetween 2400 MHz - 2485 MHz. 802.11b is compatible to 802.11g, operating with 2,4 GHz and offering a data transfer rate of 11 Mbps.
Page 7: Wireless Interface Submenu
Wireless Interface Submenu Wireless Interface Submenu The fields of the W menu are described below. IRELESS NTERACES R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0][WIRELESS]: Interface List MyGateway Network Name Status Security MAC-Filter interface --------------------------------------------------------------------- *Funkwerk-ec enable NONE disable vss0...
Page 8 To safeguard the data transferred via WLAN you should if applicable configure ➜ the options of the W menu: IRELESS IRELESS NTERFACES ■ Change the default SSID, N = Funkwerk-ec, of your access ETWORK point. ■ ➜ Set W = no. Thus all WLAN clients are IRELESS NTERFACE...
Page 9 ACCEPT list. All other clients are rejected and listed under REJECT. ➜ The generation of new wireless interfaces is carried out in W IRELESS ➜ ADD: IRELESS NTERFACES R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0][EDIT]: Wireless Interface <Funkwerk-ec> MyGateway AdminStatus enable Network Name Funkwerk-ec Name is visible Security Mode...
Page 10 Wireless Interface Submenu R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0][WIRELESS][EDIT]: Wireless Interface MyGateway AdminStatus enable Network Name Funkwerk-ec Name is visible Security Mode NONE MAC Filter > IP and Bridging > SAVE CANCEL ➜ ➜ The W EDIT menu consists of the follow-...
Page 11 Wireless Interface Submenu Field Description Security Mode The security mode (encryption and authentica- tion) of the wireless interface. Possible values: ■ NONE (default value): no encryption or au- thentication ■ WEP 40/64: WEP 40Bit ■ WEP 104/128: WEP 104Bit ■ WPA PSK (TKIP): WPA Preshared Key ■...
Page 12 Enter a string with the exact count of characters for the selected WEP mode. The phrase ends with ". For WEP40 the phrase must have 5 characters, for WEP104 13 characters. E.g. "hallo" for WEP40 "funkwerk-wep1" for WEP104. bintec User’s Guide Wireless LAN...
Page 13: Mac Filter Submenu
Enter an ASCII String of 8 - 32 characters. Table 2-1: menu fields IRELESS NTERFACES MAC Filter Submenu The fields of the MAC F submenu are described below. ILTER R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0][EDIT][MAC FILTER]: Settings MyGateway AdminStatus disable Accept Address ACCEPT REJECT ---------------------- ---------------------- Press 'a' to move selected Reject Address to Accept List.
Page 14: Ip And Bridging Submenu
Wireless Interface Submenu Default behaviour: If A = disabled, all clients are accepted. As soon DMIN TATUS as A = enabled is set and no MAC address is listed in the ACCEPT DMIN TATUS list, all clients are blocked. Only those clients whos MAC addresses are then en- tered manually into the ACCEPT list or are moved from the REJECT to the ACCEPT list are accepted.
Page 15 Wireless Interface Submenu R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0][WIRELESS][EDIT][IP CONFIGURATION]: WLAN VSS MyGateway Interface <Funkwerk-ec> local Communication disabled Local IP Address Local Netmask Second Local IP Address Second Local Netmask Bridging anable Proxy ARP SAVE CANCEL ➜ ➜...
Page 16 Wireless Interface Submenu Field Description Second Local Netmask Netmask for S IP N ECOND OCAL UMBER Bridging enable Defines the operation mode of the wireless interface. Possible values: ■ no (default value): Routing is enabled on the wireless interface. ■ yes: Bridging is enabled on the wireless in- terface.
Page 17: Advanced Submenu
Advanced Submenu Advanced Submenu The fields of the A menu are described below. DVANCED R232bw Setup Tool Funkwerk Enterprise Communications GmbH [WLAN-2-0][ADVANCED]: WLAN Specific Settings MyGateway Wireless Mode 802.11 mixed Maximum Bitrate AUTO FOUR-X Burst TX Power (dBm) SAVE CANCEL ➜...
Page 18 Advanced Submenu The menu consists of the following fields: Field Description Wireless Mode Operating mode of the AP. Possible values: ■ 802.11g: 54Mbit Clients only ■ 802.11b: 11Mbit Mode only ■ 802.11 mixed (default value) / 802.11 mixed short: 11Mbit and 54Mbit mixed mode ■...
Page 19 Advanced Submenu Field Description FOUR-X Burst This feature increases the maximum burst time for the transmission to a connected station, thus increasing the throughout in slower WLANs. ( i.e. mixed WLANs with 802.11b und 802.11g clients). FOUR-X Burst has two functions: It activates Packet Bursting.
Page 20 Advanced Submenu bintec User’s Guide Wireless LAN...
Page 21: Index: Wireless Lan
Index: Wireless LAN Numerics 802.11 b/g mixed Accept Address Access Point Active Probing 8, 12 AdminStatus Channel Default Key FOUR-X Burst local communication local IP-Number local Netmask Location MAC Filter Maximum Bitrate Name is visible Network Name Operation Mode Preshared Key Second Local IP-Number Second Local Netmask Security Mode...
Page 22 SSID TX Power (dBm) Wireless Mode bintec User’s Guide Wireless LAN...
