User's Guide

bintec R3000w / R3400 / R3800

Fast Ethernet

January 5, 2006 Funkwerk Enterprise Communications GmbH

Version 0.9

Table of Contents

Need help?

Do you have a question about the BinTec R3000w and is the answer not in the manual?

Questions and answers

Summary of Contents for Funkwerk BinTec R3000w

Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
Page 3: Table Of Contents
Fast Ethernet Menu ........3 Fast Ethernet/en1-x Menu .
Page 4 bintec User’s Guide Fast Ethernet...
Page 5: Fast Ethernet Menu
Fast Ethernet Menu Fast Ethernet Menu The fields of the F THERNET menus are described below. R3000w Setup Tool Funkwerk Enterprise Communications GmbH [SWITCH]: Fast Ethernet Configuration MyGateway Fast Ethernet/en1-0 > Fast Ethernet/en1-4 > Switch Configuration > EXIT The F...
Page 6 Fast Ethernet Menu As per default the switch is in Single Interface Mode, i.e. there is just one con- figuration for all switch ports. bintec User’s Guide Fast Ethernet...
Page 7: Fast Ethernet/En1-X Menu
Fast Ethernet/en1-x Menu Fast Ethernet/en1-x Menu The fields of the E THERNET menus are described below. R3000w Setup Tool Funkwerk Enterprise Communications GmbH [SWITCH][SLOT 1 UNIT 0 ETH]: Configure Ethernet Interface MyGateway IP-Configuration Manual local IP-Number 192.168.0.254 local Netmask 255.255.255.0...
Page 8 Fast Ethernet/en1-x Menu 1-4, the menu of which provides for equal configuration op- THERNET tions. The Ethernet ports of the switch are shipped in Single Interface Mode. The Eth- ernet interface F 1-0 is assigned and is preconfigured with THERNET IP-N 192.168.0.254 and L Note...
Page 9 Fast Ethernet/en1-x Menu Field Description Only for IP C ONFIGURATION Second Local Netmask Manual or VLAN. Netmask of the network in which your gateway with S IP N ECOND OCAL UMBER is located. Only for IP C ONFIGURATION DHCP MAC Address DHCP.
Page 10: Submenu Advanced Settings
■ IRTUAL NTERFACES Submenu Advanced Settings The fields of the A DVANCED ETTINGS submenu are described below. R3000w Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 5 ETH][ADVANCED]: Advanced Settings MyGateway RIP Send none RIP Receive none IP Accounting Proxy ARP...
Page 11 Fast Ethernet/en1-x Menu ARP and "Back Route Verify". The menu is only displayed if a L IP-N OCAL UMBER has been configured. Brief description of routing ➤➤ ➤➤ gateway receives data packets, each of which contains the des- tination host IP address. On the basis of the entries in the routing table IP ➜...
Page 12 Fast Ethernet/en1-x Menu doesn’t know its hardware address (MAC address), it sends a so-called ARP re- ➤➤ quest into the network as a broadcast. If Proxy ARP is activated on the gateway and the desired target host can be reached e.g. over a host route, the gateway answers the ARP request with its own hardware address.
Page 13 Fast Ethernet/en1-x Menu RIP S and RIP R ECEIVE contain the following selection options: Description Meaning none Not activated. Only for RIP S RIP V2 multicast For sending RIP V2 messages over the multi- cast address 224.0.0.9. RIP V1 triggered RIP V1 messages are sent rsp.
Page 14: Submenu Virtual Interfaces
The virtual interfaces are shown in the F ➜ THERNET THERNET ➜ IRTUAL NTERFACES menu. R3000w Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 5 ETH][VIRTUAL][ADD]: Configure Virtual MyGateway LAN Interface # 1 IP Configuration Manual Local IP Number Local Netmask Encapsulation...
Page 15 Fast Ethernet/en1-x Menu The V ➜ ADD/EDIT menu consists of the following fields: IRTUAL NTERFACES Field Description IP-Configuration Here you select one of four different configura- tion modes. Possible values: see table “Selection options in IP Configuration,” on page 15. Local IP Number Here you assign an IP address to the virtual interface.
Page 16 Fast Ethernet/en1-x Menu Field Description MAC Address Enter the MAC address associated with the vir- tual interface. You can use the MAC address of the physical interface under which the virtual interface was created, but this is not necessary. You can also assign a virtual MAC address. In VLAN and Manual mode, the first six 6 char- acters of the MAC address (in BRRP and BRRP over LAN mode the first ten characters)
Page 17: Submenu Advanced Settings
Fast Ethernet/en1-x Menu Description Meaning BRRP In this mode the status of the virtual interface is independent of the admin status saved in ABLE , but is defined by the tasks in the BRRP Watchdog Daemon. These are configured in the BRRP menu.
Page 18 Fast Ethernet/en1-x Menu bintec User’s Guide Fast Ethernet...
Page 19: Switch Configuration Menu
Ethernet switch of the gateway in Single Interface Mode (default) or in Split Ports Mode. You can change the switch configuration in the menu S WITCH ONFIGURATION R3000w Setup Tool Funkwerk Enterprise Communications GmbH [SWITCH][ASSIGN]: Switch Interface Assignment MyGateway Switch Port Assigned Interface Switch Port Mode...
Page 20 Switch Configuration Menu Field Description Switch Port Mode Here you choose the mode the interface is to be operated in. Available values are: ■ full autonegotiation (default) ■ auto 100 mbps only ■ auto 10 mbps only ■ auto 100 mbps/full duplex ■...
Page 21 Switch Configuration Menu If you collect several switch ports into a single interface, the bandwidth available between these ports is a full 100 Mbit/s Full Duplex. Fast Ethernet bintec User’s Guide...
Page 22 Switch Configuration Menu bintec User’s Guide Fast Ethernet...
Page 23: Index: Ethernet
Index: Ethernet 8, 15 Advanced settings 8, 9, 10 Back Route Verify Bridging DHCP Hostname DHCP MAC address 7, 13 Encapsulation ETH interfaces Fast Ethernet 8, 9, 10 IP accounting 6, 13, 14 IP configuration Local IP number local IP-Number Local netmask local Netmask 7, 13, 14...
Page 24 6, 13 Second local IP number 7, 13 Second local netmask Virtual interfaces 8, 14 VLAN ID WAN partner bintec User’s Guide Fast Ethernet...
