User's Guide
bintec R4100 / R4300

ISDN BRI

©
Copyright
July 18, 2006 Funkwerk Enterprise Communications GmbH
Version 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the bintec R4100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Funkwerk bintec R4100

Summary of Contents for Funkwerk bintec R4100

  • Page 1: Isdn Bri

    User's Guide bintec R4100 / R4300 ISDN BRI © Copyright July 18, 2006 Funkwerk Enterprise Communications GmbH Version 1.0...
  • Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.
  • Page 3 ISDN BRI Menu ......... 3 Submenu Incoming Call Answering .
  • Page 4 bintec User’s Guide ISDN BRI...

  • Page 5: Isdn Bri Menu

    ISDN BRI Menu The fields of the ISDN BRI2:0, BRI2:1, BRI2:2 resp. BRI2:3 menu are de- scribed below. R4100 Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 2 UNIT 0 ISDN BRI]: Configure ISDN MyGateway Basic Rate Interface Result of autoconfiguration...
  • Page 6 ISDN BRI Menu The ISDN BRI2: menu consists of the following fields: Field Description Result of autoconfigura- Status of ISDN autoconfiguration. Automatic ➤➤ tion: D-channel detection runs until a setting is found or until the ISDN protocol is selected manually under ISDN S WITCH .
  • Page 7 ISDN BRI Menu Field Description ➤➤ ISDN Switch Type Defines the ISDN protocol supplied by your ISDN provider. The following settings are possible: ■ autodetect on bootup: automatic D-channel detection for dialup connections (default setting) ■ Euro ISDN point to multipoint: Euro ISDN for point-to-multipoint ■...
  • Page 8 ISDN BRI Menu Field Description ■ ISDN Switch Type leased line B1+B2 channel (64S2): leased line over both B-channels (128 kbps) (cont.) ■ leased line D+B1+B2 channel (TS02): leased line over D-channel and both B- channels (144 kbps) ■ leased line B1+B2 different endpoints (dig- ital 64S with dual connection): leased line to two different endpoints.
  • Page 9 ISDN BRI Menu Field Description ➤➤ B-Channel 1 Configuration of first B-channel. The dis- play of options depends on the value selected in ISDN S WITCH . Possible values: ■ dialup (default setting): for dialup connec- tions ■ not used: NOT for dialup connections ■...
  • Page 10 ISDN BRI Menu For a leased line or if the ISDN protocol is not detected, the ISDN S WITCH can be entered manually. The automatic D-channel detection is then switched Note off. An incorrectly set ISDN protocol prevents ISDN connections being set up! In most cases, you can accept the preset values for D-C , B-C HANNEL...

  • Page 11: Submenu Incoming Call Answering

    Submenu Incoming Call Answering Submenu Incoming Call Answer- The I NCOMING NSWERING submenu is described below. R4100 Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 2 UNIT 0 ISDN BRI][INCOMING][ADD] MyGateway Item PPP (routing) Number Mode right to left Bearer SAVE...
  • Page 12 Submenu Incoming Call Answering nections to other bintec gateways. This means the gateway can be config- ured and administrated remotely. ■ ➤➤ CAPI service allows connection of incoming and outgoing data and voice calls to communications applications on hosts in the LAN that ac- ➤➤...
  • Page 13 Submenu Incoming Call Answering Field Description Number Phone number which is used to verify the called party number. It is sufficient, that only single fig- ures of the entry match considering M Mode Mode in which your gateway compares the dig- its of N UMBER with the called party number of...
  • Page 14 DOVB contains an automatic bandwidth modifi- cation from 64 kbps to 56 kbps. This function depends on the type of device. Ask the bintec Support (contact via www.funkwerk-ec.com) if DOVB can be used with your gateway. PPP V.110 Permits PPP connections to V.110 at bit rates (1200...38400)

  • Page 15: Advanced Settings Menu

    Advanced Settings Menu The fields of the A DVANCED ETTINGS menu are described below. R4100 Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 2 UNIT 0 ISDN BRI][ADVANCED]: MyGateway Advanced Settingsof BRI Interface X.31 TEI Value not specified X.31 TEI Service...
  • Page 16 Advanced Settings Menu Field Description X.31 TEI Service Here you select the service for which you want to use X.31 TEI. Possible values: ■ Packet Switch (default value) ■ Capi Default ■ Capi Set to Packet Switch if you want to use X.31 TEI for X.25 routing in your gateway.

  • Page 17: Index: Isdn Bri

    Index: ISDN BRI B-channel 1 B-channel 2 Bearer D-channel IPSec 9, 11 ISDN Login 5, 6 ISDN switch type Item 6, 7 leased dte, dce Leased line Licence usage Mode Number Point to multipoint Point to point 9, 11 PPP (routing) PPP 64k PPP DOVB PPP V.110 (1200...38400)
  • Page 18 X.25 over ISDN X.25 PAD X.31 TEI Service X.31 TEI Value bintec User’s Guide ISDN BRI...
