User's Guide
bintec R230a / R230aw / R232b / R232bw
Ethernet
©
Copyright
April 24, 2006 Funkwerk Enterprise Communications GmbH
Version 2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the bintec R230a and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Funkwerk bintec R230a

Summary of Contents for Funkwerk bintec R230a

  • Page 1 User’s Guide bintec R230a / R230aw / R232b / R232bw Ethernet © Copyright April 24, 2006 Funkwerk Enterprise Communications GmbH Version 2.0...
  • Page 2 Liability While every effort has been made to ensure the accuracy of all information in this manual, Funkwerk Enterprise Communications GmbH cannot assume liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document and is only liable within the scope of its terms of sale and delivery.

  • Page 3: Table Of Contents

    Ethernet Menu ......... . 3 XEY-100SW, Fast Ethernet menu .
  • Page 4 bintec User’s Guide Ethernet...

  • Page 5: Ethernet Menu

    Ethernet Menu Ethernet Menu The fields of the E menus are described below. THERNET These menus offer different configuration options depending on the type of de- vice for configuring the interfaces of a switch (XEY-100SW, F ) or THERNET for configuring a separate Ethernet interface (XEY-100BT, F THERNET You will find a detailed description of your gateway’s available interfaces in the User’s Guide chapter Technical Data.
  • Page 6 Ethernet Menu bintec User’s Guide Ethernet...

  • Page 7: Xey-100Sw, Fast Ethernet Menu

    XEY-100SW, Fast Ethernet menu The fields of the XEY-100SW, F menu for the Ethernet inter- THERNET face with integrated switch are described below. R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SWITCH]: Fast Ethernet Configuration MyGateway Fast Ethernet/en1-0> Switch Configuration > EXIT...

  • Page 8: Switch Configuration Menu

    XEY-100SW, Fast Ethernet menu R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SWITCH][SLOT 1 UNIT 0 ETH]: Configure Ethernet Interface MyGateway IP-Configuration Manual local IP-Number 192.168.0.254 local Netmask 255.255.255.0 Second Local IP-Number Second Local Netmask Encapsulation Ethernet II MAC Address Bridging disabled Advanced Settings >...
  • Page 9 XEY-100SW, Fast Ethernet menu R232bw Setup Tool Funkwerk Enterprise Communications GmbH [SWITCH][ASSIGN]: Switch Interface Assignment MyGateway Switch Port Assigned Interface Switch Port Mode Port 1 en1-0 full autonegotiation Port 2 en1-0 full autonegotiation Port 3 en1-0 full autonegotiation Port 4...
  • Page 10 XEY-100SW, Fast Ethernet menu Field Description Switch Port Mode Here you choose the mode the interface is to be operated in. Available values are: ■ full autonegotiation (default) ■ auto 100 mbps only ■ auto 10 mbps only ■ auto 100 mbps/full duplex ■...
  • Page 11 XEY-100SW, Fast Ethernet menu separate all switch ports, each of the resulting interfaces can use only part of the overall bandwidth. If you collect several switch ports into a single interface, the bandwidth available between these ports is a full 100 Mbit/s Full Duplex. Ethernet bintec User’s Guide...
  • Page 12 XEY-100SW, Fast Ethernet menu bintec User’s Guide Ethernet...

  • Page 13: Xey-100Bt, Fast Ethernet Menu

    XEY-100BT, Fast Ethernet menu The fields of the XEY-100BT, F menu for the separate Ethernet THERNET interface is described below. R232bw Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 5 ETH]: Configure Ethernet Interface MyGateway IP-Configuration Manual local IP-Number local Netmask...
  • Page 14 XEY-100BT, Fast Ethernet menu The Ethernet interface en1-0 is preconfigured with L IP-N OCAL UMBER 192.168.0.254 and L 255.255.255.0. OCAL ETMASK Note The E menu consists of the following fields: THERNET Field Description IP-Configuration Possible values: ■ Manual: Default value. IP address and net- mask must be entered (default value).
  • Page 15 XEY-100BT, Fast Ethernet menu Field Description DHCP MAC Address Only for IP C DHCP. ONFIGURATION MAC address of the corresponding Ethernet interface, e.g. 00e1f906bf03. Some providers use hardware-independent MAC addresses to assign their clients IP addresses dynamically. If your provider has assigned you a MAC address, enter this here.
  • Page 16 XEY-100BT, Fast Ethernet menu Field Description MAC Address Only for IP C Manual or VLAN. ONFIGURATION Here you can assign the interface another MAC address. This is only required for configurations that are more complex than the basic configu- ration, e.g. 00a0f906bf03. VLAN ID Only for IP C VLAN.

  • Page 17: Submenu Advanced Settings

    ■ IRTUAL NTERFACES Submenu Advanced Settings The fields of the A submenu are described below. DVANCED ETTINGS R232bw Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 5 ETH][ADVANCED]: Advanced Settings MyGateway RIP Send none RIP Receive none IP Accounting Proxy ARP...
  • Page 18 XEY-100BT, Fast Ethernet menu Brief description of routing ➤➤ ➤➤ gateway receives data packets, each of which contains the des- ➜ tination host IP address. On the basis of the entries in the routing table IP , the gateway decides which route to use to forward the data packet to OUTING ensure that it arrives at its destination as quickly and cheaply as possible (with the fewest possible intermediate stations).
  • Page 19 XEY-100BT, Fast Ethernet menu gateway answers the ARP request with its own hardware address. This is suf- ➤➤ ficient for establishing the connection: The data packets are sent to the gateway, which then forwards them to the desired host. Ensure that Proxy ARP is also activated at the defined WAN partner. Note ➜...

  • Page 20: Submenu Virtual Interfaces

    XEY-100BT, Fast Ethernet menu Description Meaning RIP V2 multicast Only for RIP S For sending RIP V2 messages over the multi- cast address 224.0.0.9. RIP V1 triggered RIP V1 messages are sent rsp. received and ➤➤ processed as per RFC 2091. (Triggered RIP).
  • Page 21 XEY-100BT, Fast Ethernet menu R232bw Setup Tool Funkwerk Entreprise Communication GmbH [SLOT 5 ETH][VIRTUAL][ADD]: Configure Virtual MyGateway LAN Interface # 1 IP Configuration Manual Local IP Number Local Netmask Encapsulation none MAC Address 00a0f9 Advanced Settings > SAVE CANCEL ➜...
  • Page 22 XEY-100BT, Fast Ethernet menu Field Description Encapsulation Defines the kind of header added to the IP packets that run over this interface. Possible values: ■ Ethernet II (conforms to IEEE 802.3, default value) ■ Ethernet SNAP ■ none You can generally retain the default value Ethernet II.
  • Page 23 XEY-100BT, Fast Ethernet menu Description Meaning VLAN The assignment to a VLAN is made via the VLAN ID, which is configured in this mode. A MAC address must be defined in this mode. Table 3-5: Selection options in IP C ONFIGURATION 3.2.1 Submenu Advanced Settings...
  • Page 24 XEY-100BT, Fast Ethernet menu bintec User’s Guide Ethernet...

  • Page 25: Index: Ethernet

    Index: Ethernet 15, 21 Advanced settings 15, 16, 17 Back Route Verify Bridging DHCP Hostname DHCP MAC address 13, 20 Encapsulation ETH interfaces Ethernet unit 15, 16, 17 IP accounting 12, 19, 20 IP configuration Local IP number local IP-Number Local netmask local Netmask 14, 19, 20...
  • Page 26 12, 19 Second local IP number 12, 19 Second local netmask Virtual interfaces 14, 20 VLAN ID WAN partner bintec User’s Guide Ethernet...
