Sharing on Multiple Screens

This feature allows the computer screen or media file to be shared on up to four screens
connected to other ShareLink 200 recievers.
To use this feature:
1.
2.
3.
4.

Creating a USB Thumb-drive App

This feature allows a user to load the ShareLink 200 software into a USB thumb-drive, and
to run the software directly from the drive (instead of having to install the software on a PC).
Follow these steps to load the software into, and to run the software from, a USB drive:
1.
2.
3.
4.
— Click to disconnect from any connected receivers.
Disconnect
— Click this to show the receiver information (IP address, SSID,
Show Receiver Info
and login code) briefly on the screen during a presentation, if necessary. The receiver
information overlays on top of the screen for 30 seconds, then disappears.
— Click to see the ShareLink 200 software version number.
About
— Click to exit the software program.
Exit
Click Share on Multiple Screens on the software menu. The Connected
Receivers window opens:
3 3
4 4
Figure 14. Connected Receivers Screen
Click Add New ( 2 ) to add a new reciever. Up to four receivers can be added.
Check the Screen ( 3 ) checkbox to share content to that receiver. Content is only
shared to the selected receivers.
Click the Audio button ( 4 ) to share audio to a receiver. Audio can only be shared to
one receiver.
Click Create USB Thumb-drive App in the ShareLink 200 software Advanced
Settings menu. The USB Auto Setup Wizard screen opens.
Follow the steps in the wizard screen to save the software to your USB drive. The
software requires approximately 25 MB of space.
When software loading is complete, a folder named "ShareLink 200" is saved to the
USB drive.
To run the software:
a. Plug in the USB drive to the PC that will be used for presentation.
b.
Open the folder named "ShareLink 200" that was saved to the USB drive.
c. Open the ShareLink200.exe file in the folder to run the software.
2 2
ShareLink 200 • Operation Using a Computer 15
