ShareLink Pro 2000 • Setup Guide
This guide provides instructions for installing and connecting the Extron ShareLink Pro 2000 Collaboration Gateway. The
ShareLink Pro 2000 allows anyone to present wireless or wired content from a personal device—such as a PC, laptop, smartphone,
or tablet—onto a display. It is compatible with computers with Windows
smartphones and tablets.
IMPORTANT NOTE:
Go to www.extron.com
before connecting the product to the power source.
Installation
Mounting
The ShareLink Pro 2000 can be placed on a desktop or tabletop using the included rubber feet, or mounted to a rack or furniture
CONFIG
(see the ShareLink Pro 2000 User Guide, available at www.extron.com, for mounting options and instructions).
WINDOW
e
NOTE:
Do not block or restrict air ventilation holes on the top and sides of the ShareLink Pro 2000.
B B
A A
Rear Panel Features and Cabling
INPUT OUTPUT
POWER
12V
3.0 A MAX
HDMI HDMI/CEC
A A B B C C
Figure 1. ShareLink Pro 2000 Rear Panel
Power input — Connect a power supply to this 2-pole captive screw connector.
A
HDMI input — Connect an HDMI source device to this input.
B
HDMI output — Connect an HDMI display device to this female HDMI connector.
C
Audio input — Connect a balanced or unbalanced stereo (or dual mono) line level audio source to this 5-pole 3.5 mm captive
D
screw connector. Wire the connector as shown in figure 2:
Tip
Ring
Sleeve(s)
Tip
Ring
Balanced Audio Input
Figure 2. Audio Input Captive Screw Connector Wiring
Audio output — Connect a balanced or unbalanced stereo (or dual mono) line level audio device to this 5-pole 3.5 mm captive
E
screw connector. Wire the connector as shown in figure 3:
ATTENTION:
• For unbalanced audio, connect the sleeves to the ground contact. DO NOT connect the sleeves to the
negative (–) contacts.
• Pour l'audio asymétrique, connectez les manchons au contact au sol. Ne PAS connecter les manchons
aux contacts négatifs (–).
Tip
Ring
Sleeve(s)
Tip
Ring
Balanced Audio Output
Figure 3. Audio Output Captive Screw Connector Wiring
for the complete user guide, installation instructions, and specifications
INPUT
HDMI INPUT
HDMI DECODER
SIGNAL
PASS-THROUGH
HDCP
D D
C C
AUDIO
LINE IN LINE OUT
L R L
D D E E
Tip
Left
Sleeve
Right Tip
Sleeve
Unbalanced Audio Input
Tip
Left
NO Ground Here
Sleeve(s)
Tip
Right
NO Ground Here
Unbalanced Audio Output
and macOS
®
OUTPUT USB
SS 5G
900mA
HD WIN HD PASS
STANDBY
DECODER
SCREEN
E E F F
R RESET
F F
Left
Right
Do not tin the wires!
Left
Right
Do not tin the wires!
, as well as Android and Apple
® TM
ShareLink Pro 2000
PoE+
G G
iOS
®
