Resource Assignment in Quad-XSB Mode on an M5000 Midrange Server
TABLE 4-3
XSB CPU
00-0 CPUM#0-CHIP#0
00-1 CPUM#0-CHIP#1
00-2 CPUM#1-CHIP#0
00-3 CPUM#1-CHIP#1
01-0 CPUM#2-CHIP#0
01-1 CPUM#2-CHIP#1
01-2 CPUM#3-CHIP#0
01-3 CPUM#3-CHIP#1
In , the XSB board number xx is in the range of 00-15; the IOU board
TABLE 4-4
number xx is the IOU board number corresponding to the XSB board number. For
example, XSB 00-0 has IOU#00-PCI#0.
Resource Assignment in Quad-XSB Mode on a High-end Server
TABLE 4-4
XSB CPU
xx-0 CPUM#0
Memory Board I/O
MEMB#0 Disks; GbE; IOU#0-
PCI#0, IOU#0-PCI#1,
IOU#0-PCI#2
MEMB#1 IOU#0-PCI#3, IOU#0-
PCI#4
MEMB#2 None
MEMB#3 None
MEMB#4 Disks; GbE; IOU#1-
PCI#0, IOU#1-PCI#1,
IOU#1-PCI#2
MEMB#5 IOU#1-PCI#3, IOU#1-
PCI#4
MEMB#6 None
MEMB#7 None
DIMMs I/O
MEM#00A,B IOU#xx-PCI#0,
IOU#xx-PCI#1
MEM#01A,B
MEM#02A,B
MEM#03A,B
Chapter 4 Domain Configuration 59
