SL 9000 J Console Operator's Manual

Monitor Cut and Solo

When laying tracks it is often preferable to be able to CUT and SOLO the Monitor
feeds without cutting the Pre-Fader Cue sends to the studio headphones. There is a
link option (LK3) on the upper module card which determines if the Monitor Pre-
Fader Cue sends are cut by the Monitor Cut or not.
In RECORD or REPLAY status, Large fader Cuts do not cut the Pre-Fader Aux sends if
this option has been selected.
In any other status, Pre-Small Fader Aux sends will not be cut by the Small Fader Cut
button if this option has been selected.
GROUP TAPE
24
PAN
trim
C
abs
L R
10
SF
MIX
5
PRE
LF
0
PST
LF
5
Buttons Selected
PRE LF
POST LF
Note that when 4-Channel Pan mode is selected from the computer screen, POST LF is
selected automatically, although the LED does not light.
3-16

Small Faders as Extra Auxiliary Sends

The PRE LF and P(O)ST LF buttons, next to the SMALL
FADER, provide a means of feeding the Channel signal into
the Monitor path in place of the GROUP and TAPE selections.
Note that these two buttons override any GROUP or TAPE
selection.
This is very useful in MIX status for deriving automated
auxiliary sends or clean feeds (see Section 2). These can then
be fed to the Routing Matrix and out to effects devices or cue
lines e.g. Groups 25-48 can be used as clean feeds of a live mix,
the Small Faders being used to send the Channel signal to as
many of these clean feeds as required.
Source of Small Fader Input
Pre-Large Fader
Post-Large Fader
22.12.94
