SL 9000 J Console Operator's Manual
SL911
There are four possible outputs from the channel strip:
1 2 3 4
25 26 27 28
• The Main Mix stereo bus
5 6 7 8
29 30 31 32
• The four Stereo Subgroup busses (A, B, C and D)
9 10 11 12
• The 48 Multitrack busses
33 34 35 36
• The channel's Group Output
13 14 15 16
37 38 39 40
Either or both faders can feed the Main Mix bus via the LF MIX and
17 18 19 20
SF MIX switches at the foot of the channel strip; the other three
41 42 43 44
outputs each have a source selector.
21 22 23 24
45 46 47 48
The Multitrack and Stereo Subgroup busses can be fed by Large or
1/24 25/48
Small Fader (post pan control) signals, or by one or both of the EFX
ODD/EVEN signals. If one EFX switch is selected, then the
EFX EFX
LF SF
ODD EV
corresponding routing output will be fed in mono by the selected
STEREO SUB Gp
source. Selecting both switches together will feed EFX ODD to left
A B C D
(odd) and EFX EVEN to right (even) bus. This enables any two Aux
Send controls to be re-routed to the Multitrack or Stereo busses,
EFX EFX
LF SF
ODD EV
allowing large numbers of separate mixes to be generated without
GROUP
using the Small Fader.
EFX EFX
FADER
ODD EV
BUS
The 48-track routing is accessed via 1-24/25-48 bank select switches
SUB GP
and signals are normally sourced from the Small Fader unless
FLIP
-30 0
dB
RECORD/REPLAY + SMALL FADER TO MON(itor) are selected.
0
Ø
LINE
The Stereo Subgroup bus routing has no source until one is selected.
48V
The Group Output is normally fed by the multitrack bus Mix Amp, but this can be
replaced with a post-fader channel signal by pressing FADER, or by the EFX ODD or
EFX EVEN signals.
1-6
8.9.94
