Console Overview

Centre Section

The SL 9000 J centre section is logically divided into two main areas (see the picture on
Page 1-ii). On the left, two panels provide master controls for the console's audio
functions – console status switching, main outputs and monitoring, subgroup and
auxiliary masters, meter switching, talkback, FX and cue send masters, echo returns,
oscillator etc. Below these panels, eight master control faders are provided.
The right hand side of the centre section is taken up by a large colour video monitor
and a panel housing controls associated with the J Series Computer. A jog wheel, a
standard set of transport controls, five instant locate buttons and a large timecode
display are provided for machine control. A pen and tablet interface for the computer
is provided in the fader area. See the J Series Computer Operator's Manual for more
details.
See over the page for a basic description of the centre section audio controls.
1-7
8.9.94
