Small Fader Source and Destination

The console STATUS buttons determine if the Small Fader is placed in the Monitor or
Channel signal path. (See Section 2 for more details.)
The Small Fader can be routed direct to the main stereo Mix bus by selecting the SF
MIX button.
For your reference, the sources and destinations of the Small Fader signal are shown
below. The destinations shown are the default selections; these can be over-ridden
locally at any time:
Status Buttons Selected
MIX
RECORD
RECORD +
SMALL FADER TO MON

Group/Tape Selections and the Supercue System

The GROUP and TAPE buttons are used to select monitor sources for the Monitor
fader and to determine the Pre-Fader Cue feeds. As already described, these buttons
also enable the module track RECORD facility. The table below lists the different
combinations of buttons and the resultant signals that are fed to the Monitor fader and
the Aux sends:
Ready Button
Selected
None
TAPE
GROUP
GROUP+TAPE
15.9.94
Small Fader Input
Monitor Input
Channel Input
Monitor Input
Monitor Fader
Source
TAPE
TAPE
GROUP
GROUP+TAPE
The SL911 Input/Output Module
Small Fader Output
Routing Matrix
Routing Matrix
Stereo Mix Bus
Pre-Fader
Aux Feeds
TAPE
TAPE
GROUP
GROUP+TAPE
Record Switch
Enabled?
NO
YES
YES
YES
3-13
