More On The Project Settings Pop-Up - Solid State Logic SL 9000 J Series Operator's Manual

The following elements all cover optional additions to a basic SL 9000 J system:
Routing Presets
DiskTrack System
DiskTrack Records
Please see the DiskTrack Operator's Manual for further details of the above items.
Film Scorer
PatchBay Configuration
PatchBay Presets
ScreenSound Slaves Setup
The boxes under Automation data and Total Recall Setup are used to display the
names of the last saved mix and Total Recall setup; stabbing on either box provides
access to the Mix and Total Recall setup lists.

More on the Project Settings Pop-up

If you stab on an element name in the left hand column of the display, eg. Desk Setup,
that line will turn grey and any ticks in columns to the right change to crosses (see
upper screen opposite). This enables fast deselection or reselection of elements when
setting up to use the SAVE PROJECT key, or for a local Load, Save or Clear.
If you deselect a number of elements in this way, the Mini function, when selected
(red), can be used to remove them from the displayed list (see lower screen opposite,
but note that this example may be a bit drastic for normal use!). Remember that,
depending on the number of elements you remove, it still may still be necessary to
scroll the list to view all the remaining elements. The truncated list is Project File
specific so any deselections you make will not stay in place when you load a different
project or create a new one. Deselect the Mini box to restore the list to its full length.
A combination of the above functions will obviously be useful for those facilities
which are not equipped with DiskTrack, PatchBays or ScreenSounds.
Please make sure that every operator in your facility, as well as visiting freelance
engineers, are familiar with the current Mini deselections. If items are deselected or
removed from the list, you obviously cannot save or load data for those elements of
the Project File.
16.8.96
Presets used to select different routing requirements
for DiskTrack
DiskTrack's audio routing and playlist information
DiskTrack's record arm assignments made in the
Configure menu
If your console is fitted with the Film Scoring System,
your manual will have been supplied with an
additional section containing details.
Manually made crosspoint assignments for any
automated SSL PatchBay unit on the J Series network
(see Section 7)
Up to 60 presets may be stored, each preset handling
a single crosspoint assignment for any PatchBay
(see Section 7)
All setups made in the ScreenSound Slaves
menu (see Section 7)
Projects
2-13
