The Auxiliary send section includes one stereo and 6 mono aux send
controls. The Aux On/Off function for each send is automated, with
AUXES
L R
CUE ST
push/push switches on each control toggling between on and off. A
EFX
yellow LED indicates that the send is On. Auxes can be sourced from
SF
On
either fader. The SF switch next to each send switches the source to
FX1
EFX
ODD
the small fader. The PRE switches at the bottom of the section switch
SF
On
the aux source to pre-fader. There is a PRE switch for the Stereo Cue
FX2
EFX
send and one PRE switch for each pair of mono sends.
EV
SF
On
FX3 A major advance on the SL4000 system is the FX send reassign
EFX
ODD
system – EFX for short. This allows any two mono FX sends, or the
SF
On
stereo cue send, to be disconnected from their respective busses and
FX4
EFX
EV used as sources for the channel's Group Output, the channel's Stereo
SF bus routing and/or the channel's Multitrack routing.
On
FX5
EFX
ODD
Aux sends are assigned to the EFX system using the EFX switches by
SF
On
each one. FX1, 3 and 5 can be assigned to EFX ODD. FX 2, 4 and 6
FX6
EFX
EV
can be assigned to EFX EVEN. Selecting EFX on the Stereo Cue send
SF
feeds Stereo Cue L to EFX ODD and Stereo Cue R to EFX EVEN.
On
1/2 3/4 5/6 CUE
Note that only one odd and one even numbered FX send or Stereo
PRE PRE PRE PRE
Cue can be assigned. Red (EFX ODD) or green (EFX EVEN) LEDs
indicate that a send is assigned to the EFX system.
GROUP TAPE
24
GROUP, TAPE and the Record Enable switches function identically
to the SL4000 system.
PAN
trim
C
abs
L R
The Small Fader section is similar to that on an SL4000. Both the
10
SF
fader and CUT switch are automated. The Small Fader pan is
MIX
5
located here and, unlike the SL4000, is always associated with the
PRE
LF
0
Small Fader. The pan is permanently in circuit. The Small Fader can
PST
LF
5
be assigned to the Main Stereo mix bus using the SF MIX switch.
SOLO
10
In MIX or RECORD/REPLAY + SMALL FADER TO MON(itor)
CUT
20
status, the Small Fader is normally sourced from the Monitor input.
30
In RECORD or REPLAY status the Small Fader is normally sourced
LF
40
MIX
from the channel input. This selection can be overridden by the PRE
60
ISO
LF/PST LF fader switches. The PRE LF switch will pick up the
C
channel signal immediately post input selection, or the channel
signal post signal processing. Which signal is chosen is set by an
ST
internal link option. PST LF selects the post Large Fader signal.
L R
M P
REC The Small Fader has it's own automation status switch and LEDs.
SOLO CUT
1-4
