Installing the secondary SFP+ transceiver module
Figure 84: Installing the secondary SFP+ transceiver module
Ê If applicable, install the secondary SFP+ transceiver module accordingly.
9.3.2

Removing an SFP+ transceiver module

Upgrade and Repair Unit
(URU)
Tools: tool-less
For Fiber Channel over Ethernet (FCoE) configurations, the ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
RX2540 M1
Upgrade and Maintenance Manual
Expansion cards and backup units
Hardware: 5 minutes
