  6. Installation and operating manual

Structural Concepts GP641RRLB Installation And Operating Manual

G-series refrigerated salad/sandwich case / self-service grab-n-go at front section > refrigerated pan system at top surface (behind sneeze guard) refrigerated drawers & storage door at case rear for deli meat & cheeses > refrigerated self-service gr
Hide thumbs
Table of Contents

Advertisement

Quick Links

G-SERIES
> REFRIGERATED SALAD/SANDWICH CASE / SELF-SERVICE GRAB-N-GO AT FRONT SECTION
> REFRIGERATED PAN SYSTEM AT TOP SURFACE (BEHIND SNEEZE GUARD)
> REFRIGERATED DRAWERS & STORAGE DOOR AT CASE REAR FOR DELI MEAT & CHEESES
> REFRIGERATED SELF-SERVICE GRAB-N-GO FRONT SECTION / HEATED SERVICE PIZZA DISPLAY
> REFRIGERATED SELF-SERVICE GRAB-N-GO FRONT / HEATED SERVICE PIZZA STONE DISPLAY
> REFRIGERATED SELF-SERVICE/SERVICE PREP CASE WITH REAR STORAGE, Etc.
Model GP837R
Model GP641RRLB
Model GP441RR
I:\Oper Manuals\G-Series_Grab-N-Go_GPXXXR_RR_DRLB_RHLB_RRLB_20-00045.pub
READ AND SAVE THESE INSTRUCTIONS
Model GP340DRLB.5580
Model GP236DRLB (Front Panel
To Be Attached As Part of Lineup)
888 E. Porter Road · Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
INSTALLATION
AND OPERATING
MANUAL P/N 20-00045
Model GP841R.5184
Model CDR5745A
Note: See MODEL APPLICABILITY section in this manual for a
complete list of models represented by this operating manual.
Model GP841RR
Model GP440RRLB.5571
Model GP440RHLB.5574
Rev Q Date: 5.14.2014
