OPEN REFRIGERATED SELF-SERVICE MERCHANDISER
HIGH ENVIRONMENT REFRIGERATED
MOBILE GRAB-N-GO UNITS
> DUAL ACCESS UNITS
> TYPE II ENVIRONMENT*
> DUAL ROLL-DOWN SECURITY DOORS
> SELF-CONTAINED & REMOTE UNITS
Model HEFSC663R Shown With
Roll-Down Security Door Fully Extended
Model HEFSC663R Shown With
Roll-Down Security Door Retracted
See SCC P/N 21-22808 For
Field Service Parts List.
USER MANUALS/21-22807_OASIS_USER MANUAL_HEFSC(L)63R_REF_HIGH ENV_GRAB-N-GO_MOBILE CASE
READ AND SAVE THESE INSTRUCTIONS
®
MANUAL
*Higher ambient temperature: Not to exceed 85 °F (29.4 °C) / 60% humidity. See page 3.
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
USER
Model HEFSC463R Shown With Roll-Down
Security Door Partially Extended
SCC P/N
20-22807
REV C: 10/14/2022
