Uponor Climate Control Zoning System Installation Manual page 44

Function
As a standard
room thermostat
With a floor sensor,
maximum limitation
With a floor sensor,
minimum limitation
With an
outdoor sensor
Technical alarm
Table 1: Dip Switch Chart
Step 4: Air and Sensor Settings
Adjust the settings for both the air and slab sensor
temperatures (if used).
68°/20°
Step 5: Thermostat Connection
Register the thermostat to the base unit using the
following procedure:
1. On the base unit, press and release the Test button.
2. Then press the "output" button for the actuator(s) or
outputs that it will control. The
output LED will flash.
3. Using a pointed instrument,
gently press the registration
button on the T-54 until the
output LED on the base unit is
on continuously.
38
Switch Switch Switch
1 2 3
Off Off Off
On Off Off
On Off Off
Off On Off
Off Off On
86°/30° 95°/35°
77°/25°
104°/40°
113°/45°
Floor
Switch 4. Repeat these steps to connect additional thermostats
4
to the base unit.
5. Press and release the test button to end the
Off
registration process.
Step 6: Installation
Off
Use screws or adhesive
strips (included) to attach
On
the thermostat to the
wall. Uponor recommends
Off
labeling each thermostat
with a location name
Off
along with the outputs or
actuators it controls.
Battery Replacement
Replace the thermostat batteries when the red LED
inside the thermostat flashes twice during a heating or
cooling demand.
Temperature Information
1. On the Uponor screen, select Main Menu >
Information > Rooms.
2. Select the desired room and press OK.
Icon Description
If thermostat temperature
is outside the allowed
temperature range for the
room, limitation temperature
is displayed as set point.
Measured temperature
is 70.2°F.
Temperature setting
for room when in ECO
(Economy) mode. (Current
setting 66°F).
Options for current status:
COMF: Comfort mode
ECO: Economy mode
F°/C°
This screen displays if there
is a floor sensor in the room.
Floor temperature is 75°F.
Max. and Min. — Minimum
and maximum floor
temperature set point.
Screen
