Uponor Smatrix Wave PULSE
EN
Installation and operation manual
CD0000130

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smatrix Wave PULSE and is the answer not in the manual?

Questions and answers

Related Manuals for Uponor Smatrix Wave PULSE

Summary of Contents for Uponor Smatrix Wave PULSE

  • Page 1 Uponor Smatrix Wave PULSE Installation and operation manual CD0000130...

  • Page 2: Table Of Contents

    Prepare for installation............16 Installation example.............. 17 Network connectivity............. 19 Operate Uponor Smatrix Wave PULSE room controller................75 Install Uponor Smatrix Wave PULSE room controller..21 12.1 Principle of operation............75 12.2 Normal operation without optional scheduling programs..75 Placement of room controller..........21 12.3...
  • Page 3 Contact the installer............110 17.9 Installer instructions............110 Technical data..............111 18.1 Technical data..............111 18.2 Cable specifications............113 18.3 Uponor Smatrix Wave PULSE room controller layout..114 18.4 Wiring diagram..............115 18.5 Dimensions................. 115 Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 4: Copyright And Disclaimer

    You agree to comply with all copyright laws worldwide in your use of the manual. Modification or use of any of the contents of the manual for any other purpose is a violation of Uponor’s copyright, trademark and other proprietary rights.

  • Page 5: Preface

    This installation and operation manual describes how to install and Power operate the components of the system. Warning! The Uponor system uses 50 Hz, 230 V AC power. In 2.1 Safety instructions case of emergency, immediately disconnect the power. Warnings used in this manual...

  • Page 6: Uponor Smatrix Wave Pulse System Description

    3.1 System overview Uponor Smatrix Wave consists of a room controller, a communication module (optional), thermostats, and actuators. The room controller manages the operation of the actuators when the thermostats detect a demand for heating or cooling.

  • Page 7: Uponor Smatrix Wave Pulse Components

    Digital thermostat with relative humidity sensor and operative • Heating/cooling function (advanced), and/or Comfort/ECO mode sensor switched by dry contact, public thermostat, or Uponor Smatrix Uponor Smatrix Wave T-168 Programmable digital PULSE app (requires communication module). thermostat with relative •...
  • Page 8 Note each other. Setting up a system with a communication module The following Uponor Smatrix thermostats can be used in the system: requires a mobile device (smart phone/tablet). • Uponor Smatrix Wave T-161, Page 8 Note •...
  • Page 9 When removed, an alarm is triggered (if activated). The thermostat temperature settings are adjusted using the dial. Maximum/minimum temperatures can only be set using the Uponor The thermostat can be registered as a system device, enabling extra Smatrix PULSE app (requires communication module). The 21 °C functions.
  • Page 10 • Displays Uponor logo and software version during power up sequence. Uponor recommends only using this thermostat in systems without a communication module. The scheduling function in the thermostat is • Setpoint range is 5 – 35 °C (maximum and minimum setting may switched off in systems with a communication module.
  • Page 11 Can be placed up to 30 meters away from the room controller. Mounting screws Batteries (AA 1.5 V) Expansion module The Uponor Smatrix Wave room controller can be expanded with six extra channels and actuator outputs using a Slave module. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 12: Accessories

    Components of the relay module 3.4 Accessories The illustration below shows the relay module and its components. Uponor offers a wide variety of accessories for use with the standard portfolio. CD0000034 Item Description Uponor Smatrix Wave M-161 Mounting material Uponor actuators...
  • Page 13 Temperatures can be adjusted with be reduced by delaying the opening of some actuators, as they use thermostats located in each room, or if installed with the Uponor most current while being opened. Smatrix PULSE app (requires communication module).
  • Page 14 Default operating mode of the circulation controller via a relay (dimensioned for the correct load), because of pump is set to Individual mode. Use the Uponor Smatrix PULSE app 24V AC controller output. (requires communication module) to change the setting if needed.
  • Page 15 To facilitate accurate log data, scheduling and different timer settings, the room controller receives the correct time and date from one of the input devices (communication module connected to Uponor cloud services, programmable thermostat etc). The clock can be set to automatically switch between summer and winter time (communication module connected to Uponor cloud services only).

  • Page 16: Install Uponor Smatrix Wave Pulse

    AC wall socket, or if required by local regulations, to a junction Prepare for installation, Page 16 box, connected to the mains power. Install Uponor Smatrix Wave PULSE room controller, Page 21 • Ensure that installed Uponor Smatrix components are protected Install antenna or communication module (contains an antenna).

  • Page 17: Installation Example

    T-162 SD0000011 Uponor Smatrix Wave PULSE system *) This example contains optional accessories which adds six actuator outputs (slave module M-160) to the Uponor Smatrix Wave PULSE room controller Note Caution! Setting up a system with a communication module Only 24 V Uponor actuators are compatible with the requires a mobile device (smart phone/tablet).
  • Page 18 Room sensor T-161: • Relay module M-161 with two extra output relays. • Set the value using the Uponor Smatrix PULSE app (requires See Relay module, Page 11, for more information. communication module). • Public thermostat T-163 with various functions (options B and Public thermostat T-163: •...

  • Page 19: Network Connectivity

    Setting up a system with a communication module requires a mobile device (smart phone/tablet). Note API connection only supports external control. The room controller (C) can be setup and controlled using the Uponor Smatrix PULSE app (A) and communication module (B) through different connection methods. Direct connection The Uponor Smatrix PULSE app (A) communicates with the room controller (C) via direct connection.
  • Page 20 Local Wi-Fi connection The Uponor Smatrix PULSE app (A) communicates with the room controller (C) via the local Wi-Fi network. • The mobile device connects to the same Wi-Fi router (E) as the communication module (B). • The communication module (B) and Wi-Fi router (E) are connected using either Wi-Fi or efternet.

  • Page 21: Install Uponor Smatrix Wave Pulse Room Controller

    5 Install Uponor Smatrix Wave PULSE room controller 5.1 Placement of room controller Attaching/detaching components Caution! Use the following guidelines when positioning the room controller: The transformer module is heavy and might detach if the • Position the room controller close to the manifold, just above if room controller is held upside down without the cover on.

  • Page 22: Connect Optional Slave Module

    Place a wide flat head screwdriver in the slot between the slave module and the other unit and twist until the snap-in lock releases. Repeat for the other side. Remove the slave module. Use caution not to bend the connection pins. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 23: Install Room Controller Antenna

    The antenna can be attached to any surface using adhesive tape. 1. Attach antenna with adhesive tape SI0000161 Caution! The antenna must be installed vertically for best coverage. Attach the antenna to the wall using double sided adhesive tape. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 24: Install Communication Module

    Attach the communication module back mount to the wall box. Using adhesive tape 90 x 25 SI0000147 Separate the communication module from its removable back mount. SI0000150 Attach the communication module back mount to the wall using adhesive tape. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 25 B Breakout plastic, mostly used when attached to a wall. Remove communication module is placed in a location with poor Wi-Fi the breakout plastic before mounting the back mount to the wall. reception. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 26: Connect Actuators To Room Controller

    A2 connection terminals on the relay. Each thermostat can control one or more channels. To Lead the cables from the relay through cable entries in the simplify installation and maintenance, Uponor bottom of the room controller frame. recommends that actuators controlled by the same Press the white button on the quick connector, using a thin thermostat shall be wired in sequence to the channels.

  • Page 27: Connect Input To Room Controller Gpi

    Use only one Comfort/ECO switch in the system. • Connecting external Comfort/ECO switch to the Heating/cooling switch system (public thermostat system device, or GPI), disables Forced ECO in the Uponor Smatrix PULSE app. • Connecting the external Comfort/ECO switch via the public thermostat system device, disables the Comfort/ECO option in the GPI.

  • Page 28: Connect Output To Room Controller Relays

    Common. 2) Function only available when Pump management is set to Individual, otherwise "Not used" is shown in the Uponor Smatrix PULSE app. 3) Function only available when cooling is activated. 4) Function only available when cooling is activated, otherwise "Not used" is shown in the Uponor Smatrix PULSE app.
  • Page 29 Note under the supervision of a qualified electrician. See the documentation from the circulation pump Note supplier as well as relevant Uponor wiring diagrams before connecting the pump. This connection requires a dry contact sensing input in the boiler. Note...
  • Page 30 Route the cable from/to the heating/cooling relay via a cable entry. Connect the heating/cooling relay to the connection labelled Relay 2 (BOILER). Secure the cable to/from the heating/cooling relay with a cable clamp in the enclosure. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 31 It will stop when the cooling demand is met. Relay function ECO mode is activated when the relay is closed. This function requires a communication module, and to change the setting of the relay output (Installer settings) to Comfort/ECO. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 32: Connect Room Controller To Ac Power

    Relay function The relay is closed when the Uponor Smatrix system is set to ECO. The ventilation must be setup to lower its speed when the input is closed (ECO), and to switch back when the input is opened again (Comfort).

  • Page 33: Test Actuators

    Flashing red The channel cannot be chosen for forced operation. Try again later. Actuator management may be delaying the actuator, if more than eight channels are opened at the same time. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 34: Install Uponor Smatrix Wave Room Thermostat

    6 Install Uponor Smatrix Wave room thermostat 6.1 Uponor Smatrix Wave T-161 Connect external sensor to thermostat Placement of thermostat 1.3–1.5 m SI0000045 Note For accurate temperature: attach the outdoor sensor to SD0000002 the north side of the building where it is unlikely to be •...
  • Page 35 SI0000021 Attach the thermostat to the wall using the wall bracket, screws and wall plugs. SI0000070 Use buttons < or > to move the pointer (LED flashes red) to a preferred channel. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 36: Uponor Smatrix Wave T-163

    3. Lock selected channel 6.2 Uponor Smatrix Wave T-163 Placement of thermostat SI0000071 Note It is recommended to register all channels to the thermostat at the same time. 1.3–1.5 m Press the OK button to select the channel for registration. The LED for the selected channel starts flashing green.
  • Page 37 The thermostat will perform a self test, for about 10 seconds, when starting up. The system will be blocked for input and the thermostat LED flashes during this period. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 38 The DIP switch in the thermostat must be set before it is registered. 2. Select a channel SI0000067 Use buttons < or > to move the pointer (LED flashes red) to a preferred channel. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 39: Uponor Smatrix Wave T-165

    To unregister already registered thermostats, see Unregister room controller channels, Page 77. SI0000073 6.3 Uponor Smatrix Wave T-165 Optional: To activate tamper alarm for the thermostat, set the Disable timer switch to Comfort mode ( ) before registering the thermostat.
  • Page 40 Attach the thermostat to the wall using the wall bracket and adhesive strips. CD0000004 The thermostat is delivered in a kit with screws, wall plugs, and a wall bracket, presenting several options of attaching the thermostat to the wall. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 41: Uponor Smatrix Wave T-166

    LEDs turn off to end registration and return to run mode. To unregister already registered thermostats, see Unregister room controller channels, Page 77. 6.4 Uponor Smatrix Wave T-166 Placement of thermostat SI0000068 Use buttons < or > to move the pointer (LED flashes red) to a preferred channel.
  • Page 42 CD0000004 The thermostat is delivered in a kit with screws, wall plugs, and a wall bracket, presenting several options of attaching the thermostat to the wall. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 43 Press the OK button to select the channel for registration. The LED for the selected channel starts flashing green. Select all channels to be registered to the thermostat and continue to the next step. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 44: Uponor Smatrix Wave T-168

    4. Register thermostat 6.5 Uponor Smatrix Wave T-168 Placement of thermostat 1.3–1.5 m SI0000072 Press and hold both - and + buttons on the thermostat until the text CnF (configure) and a communication icon is displayed. SD0000002 The selected channel LED in the room controller turns fixed green •...
  • Page 45 2 years of battery life, as long as it is positioned within radio range of the room controller. Ensure that the batteries are correctly inserted in the thermostat. Current software version is displayed during power up. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 46 Use buttons - or + to change the value, press the OK button to set the value and move to the next editable value. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 47 Press the OK button to select the channel for registration. The LED for the selected channel starts flashing green. Select all channels to be registered to the thermostat and continue to the next step. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 48: Uponor Smatrix Wave T-169

    4. Register thermostat 6.6 Uponor Smatrix Wave T-169 Placement of thermostat 1.3–1.5 m SI0000072 Press and hold both - and + buttons on the thermostat until the text CnF (configure) and a communication icon is displayed. SD0000002 The selected channel LED in the room controller turns fixed green •...
  • Page 49 If an external sensor is connected to the thermostat, a control mode must be selected to accommodate the extra functionality of the sensor. See 04 Control mode, Page 93, for how to change the setting. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 50 Press the OK button to select the channel for registration. The LED for the selected channel starts flashing green. Select all channels to be registered to the thermostat and continue to the next step. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 51 Press and hold the OK button on the room controller until the green LEDs turn off to end registration and return to run mode. To unregister already registered thermostats, see Unregister room controller channels, Page 77. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 52: Install Uponor Smatrix Wave Room Thermostat As System Device

    7 Install Uponor Smatrix Wave room thermostat as system device 7.1 Uponor Smatrix Wave T-163 Connect external sensor, or input signal, to thermostat Placement of thermostat 0.4 m SD0000008 SI0000047 • Ensure that the thermostat is away from any source of humidity Note and water splashes (IP20).
  • Page 53 Connecting external Comfort/ECO switch to the system (public thermostat system device, or GPI), CD0000004 disables Forced ECO in the Uponor Smatrix PULSE app. The thermostat is delivered in a kit with screws, wall plugs, and a wall bracket, presenting several options of attaching the thermostat to the •...
  • Page 54 Use buttons < or > to move the pointer (LED flashes red) to a preferred channel. SI0000065 Press and hold the OK button on the room controller until the LED for channel 1 (or the first unregistered channel) flashes red. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 55 Press and hold the OK button on the room controller until the green LEDs turn off to end registration and return to run mode. To unregister already registered thermostats, see Unregister room controller channels, Page 77. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 56: Install Uponor Smatrix Wave Thermostatic Head

    8 Install Uponor Smatrix Wave thermostatic head 8.1 Placement of thermostatic The thermostatic head use two alkaline 1.5 V AA batteries which provides about 2 years of battery life, as long as it is positioned within head radio range of the room controller. Ensure that the batteries are correctly inserted in the thermostatic head.

  • Page 57: Install Thermostatic Head On Hydraulic Radiator

    (green LED). The LED flashed red and green. Caution! Uponor recommends to not connect more than a total of 24 thermostatic heads in a system to maintain the regulating performance. The thermostatic head can be used in rooms with, or without, thermostats.
  • Page 58 2. Select a room channel SI0000088 Use buttons < or > to move the pointer (LED flashes red) to the first empty channel needed for the room (no LED). The LED flashed red. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 59 Use buttons < or > to move the pointer (LED flashes red) to the first channel of the room (green LED). The LED flashed red and green. If the first channel is full, move the pointer to the next channel in line. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 60: Install Uponor Smatrix Wave Relay Module

    Installer settings during setup (requires a communication module). Caution! 9.2 Attach relay module to the Changing status of the pump management and/or cooling allowed (in the Uponor Smatrix app, requires wall communication module) will set all relays to Not configured. Which will have to be configured again.
  • Page 61 Warning! 2) Function only available when Pump management is set to Individual, otherwise "Not used" is shown in the Uponor Smatrix PULSE app. Risk of electrical shock! Electrical installation and service behind secured 230 V AC covers must be carried out 3) Function only available when cooling is activated.
  • Page 62 Connect the cable to/from the chiller to the connector 1A and 1B module and the dehumidifier. on the relay module. Connect the cable to/from the dehumidifier to the connector 2A and 2B on the relay module. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 63: Register Relay Module To Room Controller

    When the relay is closed the external component is set to ECO. The relay is closed when the Uponor Smatrix system is set to ECO. The ventilation must be setup to lower its speed when the input is Ensure that the power is disconnected from both the relay closed (ECO), and to switch back when the input is opened again module and the other unit.
  • Page 64 LEDS on the relay module start flashing fast again, to turn off a few seconds later. SI0000071 Press the OK button to select the channel for registration. The LED for the selected channel starts flashing green. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 65: Use Relay Module To Connect Fan Coils

    9.5 Use relay module to connect fan coils Caution! SI0000044 Warning! Uponor recommends connecting no more than 4 fancoils per room controller to maintain the regulating Risk of electrical shock! Electrical installation and service performance. behind secured 230 V AC covers must be carried out under the supervision of a qualified electrician.
  • Page 66 3. LOCATE MENU 09 SI0000111 Press OK to confirm the parameter change. SI0000120 Use buttons - or + to change the numbers to 09. The text Int no is displayed. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 67 3. LOCATE MENU 09 7. CONFIRM REGISTRATION SI0000123 SI0000118 Use buttons to change the numbers to 09. The text Int no is Press OK to confirm the parameter change. displayed. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 68: Use Relay Module For Time Delayed Two Stage Additional Cooling (Requires Communication Module)

    Connect the cable to/from the component producing secondary cooling to one of the relays in the relay module. Relay 1 (30 min delay): 1A and N Relay 2 (90 min delay): 2A and N Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 69 Press and hold the register button on the relay module until the LEDs on the module start flashing slowly. SI0000122 Use buttons - or + to change Int no to Int CNF. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 70 1. Enter relay module registration mode SI0000155 Use buttons to change Int no to Int CNF. SI0000127 Press and hold the register button on the relay module until the LEDs on the module start flashing slowly. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 71 7. Confirm registration SI0000118 Press OK to confirm the parameter change. 8. Exit settings menu SI0000119 Press and hold the OK button for about 3 seconds to exit the settings menu. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 72: Install Another Uponor Smatrix Room Controller In The System

    Existing sub room controllers in the system must then either, reset system device channel 01, or register to another master room controller. Multiple Uponor Smatrix room controllers can be linked together by assigning one room controller to be master and the rest to be sub room controllers.
  • Page 73 1 on the master room controller again. But if registration feedback from the master room controller is requested, the full process can start from the beginning again without overwriting the first sub room controller registration. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 74: Finishing Installation

    Close the covers of the room controller. Attach thermostats to the wall. Print and fill in the “Installation report” (separate downloadable document). Give the printed manuals and all information about the system to the user. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 75: Operate Uponor Smatrix Wave Pulse Room Controller

    OK button until the LEDs turn off (about 3 time when there is a cooling demand. seconds). See Uponor Smatrix PULSE app for more information about the individual functions. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 76: Room Controller Leds

    12.5 Room controller LEDs Registration mode Power LED Status If the Uponor Smatrix PULSE app (requires communication module) is not used, it is recommended to occasionally check the power LED Red, fixed Room controller is in thermostat registration mode on the room controller for alarms. The power LED flashes...

  • Page 77: Reset The Controller

    SI0000065 Press and hold the OK button on the room controller until the LED for channel 1 (or the first unregistered channel) flashes red. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 78 Comfort/ECO option in the GPI. SI0000078 Press and hold the OK button on the room controller until the green 6 Not used LEDs turn off to end registration and return to run mode. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 79: Update Room Controller Software (Optional)

    12.8 Update room controller software (optional) The room controller software can be updated using the Uponor Smatrix PULSE app (requires communication module and connection to Uponor cloud services). Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 80: Operate Uponor Smatrix Pulse Communication Module

    Green, fixed Communication module is powered on and connected to Uponor cloud services. Orange, Communication module is powered on and connected to fixed LAN (using Wi-Fi or ethernet), not connected to Uponor CD0000129 cloud services. Item Description Orange, Communication module is powered on and a local...

  • Page 81: Operate Uponor Smatrix Wave Thermostats

    Uponor Smatrix Wave system. Uponor Smatrix Wave T-161 During normal operation the thermostat is monitored and controlled Analogue thermostats via the Uponor Smatrix PULSE app (requires communication module). Uponor Smatrix Wave T‑161 The illustration below shows the parts of the thermostat.
  • Page 82 Room temperature setpoint dial control Remote sensor temperature indicator (RS mode) Heating/cooling demand LED The text Err and a flashing sensor icon indicates a Backlight faulty sensor Registration button Disable timer switch Batteries Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 83 Enter and exit the settings menu • Confirm a setting Communication indicator Indoor temperature indicator Remote sensor temperature indicator (RS mode) The text Err and a flashing sensor icon indicates a faulty sensor Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 84 The text Err and a flashing outdoor sensor icon indicates a faulty sensor Relative humidity limit reached (high limit) This symbol is only shown if cooling is active, and if RH control is be activated in the Uponor Smatrix PULSE app (requires communication module). Settings menu CD0000076...
  • Page 85 This symbol is only shown if cooling is active, and if The figure shows all possible symbols and characters that can be RH control is be activated in the Uponor Smatrix shown on the display: PULSE app (requires communication module).

  • Page 86: Start Up

    Current software version is displayed during power up. CD0000082 Item Icon Description T-168 Relative humidity level Relative humidity reading using two digital characters. Indicated with a “%” character Current software version is displayed during power up. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 87 Use buttons - or + to change the value, press the OK button to set the value and move to the next editable value. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 88: Adjust Temterature

    Uponor Smatrix Wave T-161 The screen shows the current setpoint flashing. The setpoint for the thermostat can only be changed via the Uponor Press the - or + button repeatedly to adjust the setpoint Smatrix PULSE app (requires communication module). Otherwise the temperature.

  • Page 89: Analogue Thermostat Functions

    Relative humidity Floor temperature Run mode Remote sensor During normal operation the thermostat is in run mode. Remote sensor (default) While in run mode the display shows specific control mode Relative humidity information. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 90 About about 60 seconds later, it exits to run mode. In this menu all settings regarding the operation of the thermostat is set. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 91 Comfort (black marker) or ECO mode (blank marker). This menu is not visible if a communication module is connected to the system. Settings are referred to the Uponor Smatrix PULSE app. If Off (default) is selected, the room follows the current system Comfort/ECO mode.
  • Page 92 Repeat steps 6 and 7 until the display shows 23:30. Figure 6. Program P4 Press + to finalize the current day and the software exits to the settings menu. 10. Repeat from step 1 to customise another day. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 93: Control Mode

    This menu is not visible if a communication module is connected to menu 04. For systems with a communication module this menu only the system. The setting is then available in the Uponor Smatrix shows the set value, changes are done in the Uponor Smatrix PULSE app.
  • Page 94 Display text Description This menu is not visible if a communication module is connected to Not integrated the system. The setting is then available in the Uponor Smatrix Integrated (requires to be registered with the Move PULSE app. supply controller first) Register with the Move supply controller/relay See Change settings, Page 90, for how to change the setting.

  • Page 95: Replace Batteries

    Replace the batteries. Do not factory reset the thermostat if not absolutely needed. Note A factory reset removes the registration data from the thermostat. Factory reset sets all parameter values to default settings. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 96 The thermostat is now reset to factory default. Press and hold the , and OK buttons for about 5 seconds until the screen goes blank. The thermostat is now reset to factory default. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 97: Operate Uponor Smatrix Wave Thermostatic Head

    15 Operate Uponor Smatrix Wave thermostatic head The thermostatic head provides an option to control the temperature Item Icon Description in a room using radiators. It has a display relaying information to the Communication indicator user and buttons for control.

  • Page 98: Start Up

    About about 60 seconds later, it exits to run mode. In this menu all settings regarding the operation of the thermostatic head is set. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 99: Factory Reset

    To factory reset the thermostatic head: Press and hold the -, + and OK buttons for about 10 seconds until the screen goes blank. The thermostatic head is now reset to factory default. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 100: Maintenance

    The exercise periodically opens and closes the actuators. If the system includes a communication module, the exercise function can be activated at any time using the Uponor Smatrix PULSE app. 16.3 Corrective maintenance Fallback mode...

  • Page 101: Troubleshooting

    • The thermostats of individual rooms are incorrectly registered with the Uponor Smatrix system and describes solutions. A common cause of a problem though may be due to wrongly installed loops or Place the thermostat in the correct room or change the mixed up thermostats.

  • Page 102: Troubleshooting After Installation

    Disturbing noise from the pump at the same time every week The power indicator in the room controller is off • Change time for pump exercise in the Uponor Smatrix PULSE • There is no AC power to the room controller app (requires communication module)

  • Page 103: Digital Thermostat Alarms/Problems

    This symbol is only shown if cooling is active, and if RH • More than one Comfort/ECO switch is connected to the system control is be activated in the Uponor Smatrix PULSE app (requires communication module). (to the GPI and public thermostat system device)
  • Page 104 The figure shows all possible symbols and characters that can be temperature setpoint shown on the display: Replace thermostat Relative humidity icon is displayed (T-168 only) Note RH control is activated in the Uponor Smatrix PULSE app (requires communication module). • The relative humidity limit is reached CD0000080 Item...

  • Page 105: Analogue Thermostat Alarms/Problems

    Relative humidity icon is displayed in the alarm list Note RH control is activated in the Uponor Smatrix PULSE app (requires communication module). • The relative humidity limit is reached Lower the humidity level by increasing the ventilation or activating a dehumidifier °C...

  • Page 106: Thermostatic Head Alarms/Problems

    Alarms shown in Uponor Smatrix PULSE app • The batteries are discharged or wrong type of batteries are used If an alarm is triggered, it will be shown as an alert in the Uponor Replace the batteries Smatrix PULSE app. Information about, and possible solutions are •...
  • Page 107 There is an communication error with the communication module. The room controller LED is flashing red. Restart the controller and communication module (unplug and plug in the controller from the wall socket) and try again. Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 108 Restart the router if needed. Note Restart the controller and communication module if needed (unplug and plug in the controller from the wall RH control is activated in the Uponor Smatrix PULSE socket). app (requires communication module). • An error has been detected with the internal relative humidity The communication module has re-established sensor in the thermostat.

  • Page 109: Room Controller Alarms/Problems

    Replace the communication cable if needed. This alarm is only shown if Supply diagnostics is running (the function Contact the installer or replace the communication module requires connection to Uponor cloud services). Bad Wi-Fi connection • The supply temperature is too high.

  • Page 110: Contact The Installer

    If the loop becomes warm, the cause could be the room control system. A supply system defect can be indicated by no warm water in the manifold. Check the boiler and circulation pump. Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 111: Technical Data

    Max. ambient RH (relative humidity) 85% at 20 °C CE marking Low voltage tests EN 60730-1* and EN 60730-2-9*** EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3 Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 112 Low voltage tests EN 60730-1* and EN 60730-2-9*** EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3 ERM (electromagnetic compatibility and radio spectrum matters) tests EN 300 220-3 Power supply From room controller Uponor Smatrix Wave PULSE Installation and operation manual...

  • Page 113: Cable Specifications

    IP20, class II (IP: degree of inaccessibility to active parts of the product and degree of water) Max. ambient RH (relative humidity) 85% at 20 °C CE marking ERP (with communication module and the Uponor Smatrix PULSE app) VIII ERP (without communication module and the Uponor Smatrix PULSE app) Low voltage tests...

  • Page 114: Uponor Smatrix Wave Pulse Room Controller Layout

    Room controller: Up to 4.0 mm² controller GPI input solid, or 2.5 mm² flexible with ferrules Relay: 1.0 mm² to 4.0 mm² 18.3 Uponor Smatrix Wave PULSE room controller layout CD0000118 Item Description Transformer, 230 V AC 50 Hz power module Fuse (T5 F3.15AL 250 V)

  • Page 115: Wiring Diagram

    18.4 Wiring diagram Uponor Smatrix Wave PULSE room controller GPI 1 > 40 cm GPI 2 RELAY 1 (PUMP) GPI 3 WD0000019 Uponor Smatrix Wave PULSE slave module WD0000020 18.5 Dimensions Uponor Smatrix Wave PULSE room controller 55 mm 336 mm...
  • Page 116 Uponor Smatrix Wave PULSE room controller and slave module 476 mm 55 mm 84 mm 245 mm 140 mm 72,5 mm 110 mm 110 mm CD0000120 Communication module 55 mm 19 mm 60 mm 110 mm CD0000128 Thermostats Uponor Smatrix Wave T-161...
  • Page 117 Uponor Smatrix Wave T-169 80 mm 80 mm 60 mm 38 mm 26,5 mm 9 mm CD0000124 CD0000125 Thermostatic head Uponor Smatrix Wave T-162 99 mm 16 mm 69 mm 87 mm CD0000126 Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 118 Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 119 Uponor Smatrix Wave PULSE Installation and operation manual...
  • Page 120 Uponor GmbH Industriestraße 56, D-97437 Hassfurt, Germany Uponor reserves the right to make changes, without prior notification, 1095344 04_2019_EN to the specification of incorporated components in line with its policy of www.uponor.com Production: Uponor/MRY continuous improvement and development.
