Connecting Base Unit Power Source and Selecting
Programming Language
1. Check that the wiring is complete.
2. Ensure power compartment is closed.
3. Connect base units #2 and #3 to the power.
4. Check that the language data stick is connected at the
back of the interface.
5. Ensure power compartment is closed. Connect base
unit #1 to the power.
6. Select a language by pressing the
select the language.
7. Press OK to confirm.
22
Language
English
Svenska / Sedish
German / Deutsch
or
• If the language data stick is inserted, the
language screen will automatically appear at
first installation.
• The language setting is saved in case of
power failure.
• The language can be changed after first
installation by re-inserting the language stick.

Time and Date Setup

This screen will open automatically when the language
has been set.
Set Date/Time
01 Jan 2008
Select time and date with the keys.
Set Date/Time
01 Jan 2008
Set Date/Time
01 Jan 2008
Set Date/Time
01 Jan 2008
keys to
Set Date/Time
01 Jan 2008
Set Date/Time
01 Jan
1. Select hours.
2. Set the hour.
3. Select minutes.
4. Set the minutes and continue until the date is set.
5. Press OK to confirm.
00 : 00
02
01
00 : 00
00
23
22
14
13
12 : 00
12
11
10
02
01
12 : 00
00
59
58
26
25
12 : 24
24
23
22
2010
2009
12 : 24
2008
2007
2008
2006
Uponor
17 Mar 2008 12 : 24
