Exercise Actuators and Pumps

Cancel Exercise
1. Uponor screen
Parameters
>
2. Press OK.
Exercise Valve and Pump
1. Uponor screen
Parameters
and Pump
2. Set the time and date for the
five-minute activation.
>
Press OK.
Exercise Actuator Only
1. Uponor screen
Parameters
Valve Only
2. Set the time and date for the five-
minute activation.
>
Press OK.

Temperature Unit

1. Uponor screen
Settings
Temperature Unit
>
2. °C or °F
>
Press OK.

Backlight

1. Uponor screen
Settings
Backlight
2. Select:
Always ON
Dimmed (when inactive): reduced screen brightness
OFF (when inactive): backlighting off
>
Press OK.

Installer Level

The Installer access level provides additional access to:
• The information menu
• All advanced level parameters
• Pump management settings
• Base unit identification
• Language
32
This exercise maintains the functionality of the
actuators and pumps. A five-minute activation
is scheduled every week.
> > >
Main Menu Settings
> >
Valve/Pump Exercise Cancel Exercise
Exercise Setup
Cancel Exercise
Exercise Valve and Pump
Exercise Valve Only
> > >
Main Menu Settings
> >
Valve/Pump Exercise Exercise Valve
Exercise Time
> > >
Main Menu Settings
> >
Valve/Pump Exercise Exercise
Exercise Time
> >
Main Menu
Temperature Unit
> >
System Parameters Please choose the
required temp unit.
˚C
> >
Always ON
Main Menu
Dimmed (when inactive)
> >
System Parameters
OFF (when inactive)
The device has another mode: the Installer
level. Only the installer should set these
settings.

Vacation Mode

Vacation mode allows the user to easily set a temperature
reduction common to all rooms. The thermostat settings
are ignored during this period. The symbol
Uponor screen indicates that the system is in
Vacation mode.
System
• The reduce vacation setpoint applies
throughout the installation for all installed
room thermostats. The setting range is
41°F to 95°F.
• The minimum and maximum limitations have
System
priority over the Vacation mode reduction.
For example if the minimum and maximum
temperature range of a room is set to 68°F
Monday
to 77°F, and the holiday temperature is set
1 : 00
to 59°F for all rooms, the temperature for
this room will not drop below 68°F.
Applying the Vacation Mode
1. Uponor screen > Main Menu > Vacation Mode >
System
Apply Vacation Mode
Set Date/Time
Monday 2 : 02
1 : 00
14 Jan 2008
End Date
2 : 02
15 Jun 2008
Vacation Temperature
59˚F
˚F
Example: Vacation Mode can be cancelled before the
date is entered into the system.
Backlight
Cancelling the Vacation Mode
1. Uponor screen > Main Menu > Vacation Mode >
Cancel Vacation Mode
Cancel Vacation
Mode?
Yes
No
on the
2. Enter time and date for the start
of the vacation period
> Press OK.
3. Enter time and date for the end
of the vacation period
> Press OK.
4. Enter the Vacation temperature
setpoint > Press OK.
Cancel Vacation Mode
2. Select Yes > Press OK.
