A P P E N D I X D
Integrating other devices
3. Press the Input button on the ECP or remote control to switch input sources to the laptop
computer.
To connect a laptop to a SMART Board 800ix2-SMP interactive whiteboard system
1. Connect the laptop computer to the SMART GoWire cable, and then connect the
SMART GoWire cable to the CAT 5 USB extender.
OR
Connect the laptop computer directly to the CAT 5 USB extender.
2. Connect a VGA cable from the laptop computer to the computer.
OR
Connect an HDMI cable from the laptop computer to the projector.
N O T E S
If you use an HDMI cable, change the USB port mapping so that USB-2 is associated
o
with the HDMI-2 input.
Do not use a DVI to HDMI adapter.
o
Do not use a DVI-D-to-HDMI cable. DVI-D doesn't carry audio and you'll have audio
o
problems.
3. Press the Input button on the ECP or remote control to switch input sources to the laptop
computer.
79 smarttech.com/kb/170453
