  • Page 1 Installation, Operation and Maintenance Instructions 3175...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1 Introduction and Safety ............................ 3 1.1 Introduction and Safety ..........................3 1.1.1 Introduction ............................. 3 1.1.2 Safety .............................. 3 1.1.3 Product approval standards ......................8 1.1.4 Product warranty ..........................9 1.1.5 ATEX Considerations and Intended Use..................10 2 Transportation and Storage..........................
  • Page 4 Table of Contents 5.14 Priming ..............................38 5.15 Start the pump............................43 5.16 Pump operation precautions ......................... 43 5.17 Initial Inspection After Starting....................... 44 5.18 Final Alignment............................45 5.19 Doweling..............................45 5.20 Stuffing Box Operation .......................... 46 5.21 Operating at Reduced Capacities ......................46 5.22 Operating at Reduced Head........................

  • Page 5: Introduction And Safety

    For instructions, situations, or events that are not consid- ered in this manual or in the sales documents, please contact the nearest ITT representative. Always specify the exact product type and identification code when requesting technical information or spare parts.
  • Page 6 Risk of injury and/or property damage. Operating a pump in an inappropriate application can cause over pressurization, overheating, and/or unstable operation. Do not change the service application without the approval of an authorized ITT representative. 1.1.2.1 Safety terminology and symbols...
  • Page 7 WARNING: If the product has been contaminated in any way, such as from toxic chemicals or nuclear radi- ation, do NOT send the product to ITT until it has been properly decontaminated and advise ITT of these conditions before returning.
  • Page 8 1.1 Introduction and Safety • Avoid all electrical dangers. Pay attention to the risks of electric shock or arc flash hazards. • Always bear in mind the risk of drowning, electrical accidents, and burn injuries. Safety equipment Use safety equipment according to the company regulations. Use this safety equipment within the work area: •...
  • Page 9 Personnel requirements These are the personnel requirements for Ex-approved products in potentially explosive atmospheres: • All work on the product must be carried out by certified electricians and ITT-authorized mechanics. Special rules apply to installations in explosive atmospheres. • All users must know about the risks of electric current and the chemical and physical characteristics of the gas, the vapor, or both present in hazardous areas.

  • Page 10: Product Approval Standards

    Use of equipment unsuitable for the environment can pose risks of ignition and/or explosion. Ensure the pump driver and all other auxiliary components meet the required area classifica- tion at the site. If they are not compatible, do not operate the equipment and contact an ITT representative before proceeding.

  • Page 11: Product Warranty

    All service and repair work is done by ITT-authorized personnel. • Genuine ITT parts are used. • Only Ex-approved spare parts and accessories authorized by ITT are used in Ex-approved prod- ucts. Limitations The warranty does not cover faults caused by these situations: •...

  • Page 12: Atex Considerations And Intended Use

    Maintenance manual (IOM) can cause serious personal injury or damage to the equipment. This in- cludes any modification to the equipment or use of parts not provided by ITT Goulds Pumps. If there is any question regarding the intended use of the equipment, please contact an ITT Goulds representative before proceeding.

  • Page 13: Transportation And Storage

    2 Transportation and Storage 2 Transportation and Storage 2.1 Transportation and Storage 2.1.1 Inspect the delivery 2.1.1.1 Inspect the package Inspect the package for damaged or missing items upon delivery. Note any damaged or missing items on the receipt and freight bill. File a claim with the shipping company if anything is out of order.
  • Page 14 2.1 Transportation and Storage • Lifting and handling heavy equipment poses a crush hazard. Use caution during lifting and handling and wear appropriate Personal Protective Equipment (PPE, such as steel- toed shoes, gloves, etc.) at all times. Seek assistance if necessary. Table 2: Methods Pump type Lifting method...

  • Page 15: Storage Guidelines

    2.1 Transportation and Storage Figure 4: Example of a proper lifting method NOTICE: Do not use this method to lift a Polyshield ANSI Combo with the pump and motor mounted. These items are not designed to handle the heavy weight of the Polyshield system. Doing so may result in equipment damage.
  • Page 16 You can purchase long-term storage treatment with the initial unit order or you can purchase it and apply it after the units are already in the field. Contact your local ITT sales representative. 2.1.3.2 Frostproofing...

  • Page 17: Product Description

    Use of equipment unsuitable for the environment can pose risks of ignition and/or explosion. Ensure the pump driver and all other auxiliary components meet the required area classifica- tion at the site. If they are not compatible, do not operate the equipment and contact an ITT representative before proceeding.

  • Page 18: Installation

    Electrical connections must be made by certified electricians in compliance with all inter- national, national, state and local regulations. • Supervision by an authorized ITT representative is recommended to ensure proper instal- lation. Improper installation may result in equipment damage or decreased performance. 4.2 Location Pumping unit should be placed as close as practical to the source of supply.

  • Page 19: Install Horizontal Pumps

    4.4 Install Horizontal Pumps Lower the assembled pump (less motor) carefully into the pit. Guide unit carefully so that it does not strike sides of pit. When unit is in place, level the support plate. Shim under support plate as re- quired.
  • Page 20 4.4 Install Horizontal Pumps 1. Dam 5. Bedplate 2. Wedges 6. Grout 3. Leave 3/4" to 1-1/2" under bedplate for grout 7. Leave top of foundation rough and wet before grouting 4. Waste 8. Concrete foundation Figure 10: Concrete Foundation The I.

  • Page 21: Pump-To-Driver Alignment

    4.5 Pump-to-driver alignment NOTICE: "Spider-Insert" couplings, as shown in the image below, need not be disconnected. Figure 12: Spider-Insert Couplings By adjustment of wedges, bring the bedplate to an approximate level and provide the proper dis- tance above the foundation for grouting 10.05mm to 38.1mm | 3/4" to 1-1/2". Level or plumb the suction and discharge flanges.
  • Page 22 4.5 Pump-to-driver alignment NOTICE: This is an initial alignment. The final alignment is done after the unit has been run under actual operating conditions. The final alignment procedure is outlined in 5.18 Final Alignment on page and must be followed. Make sure: motor starting switch is "locked out" to prevent acciden- tal rotation.
  • Page 23 4.5 Pump-to-driver alignment Set motor shaft .002"-.004" low regardless of pumpage temperature. Figure 14: Pedestal Mounted Units Figure 15: Casing Mounted Units Option Description Pumpage Temperature Above Ambient Motor Temperature Shaft Option Description Ambient 0.051mm - 0.102mm | 0.002" - 0.004" Low 38°C | 100°F 0.000mm - 0.051mm | 0.000"...
  • Page 24 4.5 Pump-to-driver alignment Figure 16: Parallel Alignment with Straight edge Flexible Spacer Couplings: Place a dial indicator on one hub and rotate that hub 360° while tak- ing readings on the outside diameter of the other hub. When indicator does not deflect more than 0.051mm | 0.002"...

  • Page 25: General Piping

    4.6 General Piping alignment by using calipers at 90° intervals on the circumference on the outer end of hubs. When caliper measurements are identical, the unit is in angular alignment. See image below. Figure 19: Angular Alignment with Calipers Flexible Spacer Couplings: Place a dial indicator on one shaft hub and rotate that hub 360°. Take readings from the face of the other hub.

  • Page 26: General Suction Piping

    4.7 General Suction Piping The piping, both suction and discharge, should be as short and direct as possible. Avoid all un- necessary elbows, bends, and fittings, as they increase the friction losses in the piping. The size of pipe and fittings should be carefully selected and of sufficient size to keep the friction losses as low as practical.
  • Page 27 4.7 General Suction Piping only providing there is a minimum of two diameters of straight pipe between the elbow and pump suction flange. 1. Elbow must be vertical when next to pump Figure 22: Wrong 1. Eccentric reducer - with top horizontal 2.
  • Page 28 4.7 General Suction Piping 1. Strainer 5. Eccentric reducer 2. Foot valve (if used) 6. Check valve 3. Long radius elbow 7. Gate valve 4. Suction pipe slopes upwards from source of sup- Figure 25: Correct Piping 1. Air pocket because eccentric reducer is not used and because suction pipe does not slope gradually up- ward from supply 2.

  • Page 29: Suction Piping Design For Large Pumps

    4.8 Suction Piping Design for Large Pumps 1. Pump Figure 28: Incorrect Piping Arrangement 4.8 Suction Piping Design for Large Pumps Large units taking their suction supply from sumps require special attention. A properly designed sump is a must. The larger the unit, the more important these considerations become. A 3000 GPM pump should be considered a large unit.

  • Page 30: Installations With Pump Above Source Of Supply - Suction Lift

    4.8 Suction Piping Design for Large Pumps Figure 32: Neither Recommended Min O = 45° Preferred O = 75° Figure 33: Recommended Figure 34: Not Recommended The velocity of the water approaching the pump suction pipe should be kept to a maximum of one foot per second to avoid air being drawn into the pump.

  • Page 31: Discharge Piping

    4.9 Discharge Piping Keep suction pipe free from air pockets. 4.9 Discharge Piping Gate and check valves should be installed in the discharge line. The check valve should be locat- ed between the gate valve and pump to permit inspection of the check valve. The gate valve is required for priming, regulation of flow and for inspection and maintenance of the pump.
  • Page 32 4.12 Connection of Coupling • Electrical connections must be made by certified electricians in compliance with all inter- national, national, state, and local rules. • Refer to driver/coupling/gear manufacturer's installation and operation manuals (IOM) for specific instructions and recommendations. Connect coupling. Follow the manufacturer’s instructions. "Spider-Insert"...

  • Page 33: Commissioning, Startup, Operation, And Shutdown

    5 Commissioning, Startup, Operation, and Shutdown 5 Commissioning, Startup, Operation, and Shutdown 5.1 Preparation for startup WARNING: • Risk of serious physical injury or death. Exceeding any of the pump operating limits (e.g. - pressure, temperature, power, etc.) could result in equipment failure, such as explosion, seizure, or breach of containment.

  • Page 34: Pump Bearings

    5.2 Pump Bearings NOTICE: • Verify the driver settings before you start any pump. Refer to the applicable drive equip- ment IOMs and operating procedures. • Excessive warm-up rates can cause equipment damage. Ensure the warm-up rate does not exceed 1.4°C | 2.5°F per minute. •...

  • Page 35: Driver Bearing And Coupling

    5.3 Driver Bearing and Coupling Under normal operating conditions, an oil of 300 SSU viscosity at 38°C | 100°F. (approximately SAE-20) should be used. For extreme conditions refer to the factory or a lubrication expert for a recommendation. Fill the bottle with the proper grade of oil and replace in the oiler housing. Oil reservoir in bearing housing is filled when an oil level remains in the bottle.
  • Page 36 5.4 Stuffing Box Packing • Electrical connections must be made by certified electricians in compliance with all international, national, state, and local rules. • Refer to driver/coupling manufacturer's installation and operation manuals (IOM) for specific instructions and recommendations. NOTICE: Make sure to lubricate the packing. Failure to do so may result in shortening the life of the packing and the pump.

  • Page 37: Remove Packing

    5.5 Remove Packing below. Use gland to jack the bushing and ring into the box. Stagger joints in each ring 90°. Make sure center of lantern ring lines up with flush tap in the stuffing box. Any extra rings are spares. Figure 40: Wooden split bushing 1.

  • Page 38: Connection Of Sealing Liquid Or Grease Lubricator (Packed Box)

    5.7 Connection of Sealing Liquid or Grease Lubricator (Packed Box) manufacturers' installation drawings are attached to the pump. The seals are installed and adjusted at the factory. The manufacturer's drawings should be filed for future use in maintaining the seal and in ad- justing the seal when the pump is disassembled.

  • Page 39: Connection Of Drain Piping

    5.9 Connection of Drain Piping Casing Pedestals On some models, water cooled pedestals are available. Connection of coolant lines is made in the same manner as above. Mechanical Seals Seal materials (carbon, ceramic, PTFE, etc.) are suitable for use at temperatures to 260°C | 500°F. (100°C to 121°C | 212°F to 250°F if seal has rubber parts).

  • Page 40: Check For Free Turning

    5.12 Check for Free Turning 5.12 Check for Free Turning WARNING: • Starting the pump in reverse rotation can result in the contact of metal parts, heat genera- tion, and breach of containment. Ensure correct driver settings prior to starting any pump. •...
  • Page 41 5.14 Priming NOTICE: On glass-lined pumps, the thermal shock limit of the glass varies with the conditions of opera- tion. Do not introduce liquid to pump if temperature difference between liquid and pump is 100°F. Gradually heat pump before introducing hot liquids. Suction Supply Above Pump When pump is installed as shown below, pump will prime itself.
  • Page 42 5.14 Priming 1. Foot valve 4. Air vent valves 2. From some outside supply 5. Discharge gate valve 3. Shut off valve Figure 42: Foot valve By Separate Hand, or Manually Controlled, Priming Pump: Close discharge gate valve (keep air vent valves dosed) and open valve in line to priming pump. Exhaust air from pump and suc- tion piping until water flows from priming pump.
  • Page 43 5.14 Priming In methods a and b above, the pump will remain primed, provided foot valve is tight. Any failure, however, of foot valve when pump is standing idle, will permit the pump to lose its prime. During long idle periods, the pump can also lose its prime through leakage from stuffing boxes. Bypassing Around Discharge Check Valve: This method can be used only when there is liquid under some pressure in the discharge line.
  • Page 44 5.14 Priming 1 - Ejector 4 - Steam, compressed air, or water under pressure 2 - Valve "S" 5 - Discharge gate valve 3 - Valve "E" Figure 45: Ejection Close discharge gate valve, open valve "E" in steam, air or water pressure supply line. Open valve "S"...

  • Page 45: Start The Pump

    5.15 Start the pump A vacuum tank and a vacuum gauge can be installed near the primer pump and the vacuum switch set to automatically start or stop the primer pump according to the vacuum required to keep the system primed. 5.15 Start the pump WARNING: Risk of equipment damage, seal failure and breach of containment.

  • Page 46: Initial Inspection After Starting

    5.17 Initial Inspection After Starting NOTICE: • Risk of equipment damage from unexpected heat generation. Do not overload the driver. Ensure that the pump operating conditions are suitable for the driver. The driver can overload in these circumstances: • The specific gravity or viscosity of the fluid is greater than expected •...

  • Page 47: Final Alignment

    5.18 Final Alignment Mechanical Seal The mechanical seal was adjusted at the factory. If the seal leaks slightly when pump is first started, a few hours run-in will allow seal to adjust itself. Never run seal dry. Make sure cooling flow lines, if any, are operating properly.

  • Page 48: Stuffing Box Operation

    5.20 Stuffing Box Operation On units to be doweled (except those noted above), drill through two diagonally opposite feet of the pump into the bedplate. Use a reamer with a ¼" per foot taper. The dowels should extend well into the bedplate but project above the pump feet.

  • Page 49: Operating At Reduced Head

    5.22 Operating at Reduced Head Liquid temperature relay or thermostat which will shut off the unit if the liquid temperature in the pump exceeds a predetermined maximum. This device guards against possible damage due to running the pump against a closed valve. Constant open by-pass orifice between the pump discharge and any check or regulating valve in the discharge line.

  • Page 50: Maintenance

    These bearing lubrication sections list different temperatures of the pumped fluid. If the pump is ATEX-certified and the temperature of the pumped fluid exceeds the permitted temper- ature values, then consult your ITT representative. All bearings operate at some temperature above that of the surrounding atmosphere, unless cooled.

  • Page 51: Bearing Removal

    6.1 Bearing Maintenance Repeat until bearing is completely clean. Blow dry with clean filtered compressed air. With ball bearings, hold the two races together, but allow the inner race to rotate a few turns now and then to dislodge the kerosene from the retainer pockets. When the bearing has been blown dry, oil it immediately with a good grade of clean machine oil to prevent corrosion or rust.

  • Page 52: Install The Ball Bearings

    6.1 Bearing Maintenance Figure 48: Bearing puller NOTICE: Do not damage the end of the shaft. Sleeve Bearings After the bearing shells have been removed, a bearing puller, such as shown above should be used to remove the ball bearing. The puller bar must be "square"...

  • Page 53: Lubricate The Pump

    6.2 Lubricate the Pump 6.2 Lubricate the Pump WARNING: Risk of explosive hazard and premature failure from sparks and heat generation. Ensure bearings are properly lubricated prior to startup. Oil Lubrication Refer to 5.2 Pump Bearings on page 32 for oil specifications. Oil lubricated ball bearings are stand- ard on the Model 3175.
  • Page 54 6.2 Lubricate the Pump Refer to 5.2 Pump Bearings on page 32 for grease specifications. Grease lubrication is optional on the Model 3175. These units can be identified by the grease fitting located on the bearing housing. Bearings are lubricated at the factory. Do not grease at too frequent intervals. To lubricate pump: Insert grease through grease fittings while shaft is rotating, until clean grease appears through the relief caps.

  • Page 55: Impeller Clearance Adjustment

    6.3 Impeller Clearance Adjustment 6.3 Impeller Clearance Adjustment WARNING: Failure to disconnect and lock out driver power may result in serious physical injury or death. Always disconnect and lock out power to the driver before performing any installation or main- tenance tasks.
  • Page 56 6.3 Impeller Clearance Adjustment A - Feeler Gauge Figure 52: Feeler Gauge Method Dial·Indicator Method Remove one bolt (370C) and thread a pipe or rod in its place. This is to hold a dial indicator as shown below. Loosen adjustment bolts and nuts (371A & 423B). Tighten each bolt (370C) evenly, while slowly rotating the shaft, until impeller just starts to rub against casing.

  • Page 57: Disassembly Precautions

    6.4 Disassembly precautions Figure 53: Dial Indicator Method When either of the above methods, the rotating element and impeller have been moved 0.20mm to 0.38mm | 0.008" to 0.015" away from the casing, thus giving the required clearance between these two parts.

  • Page 58: Disassemble The Pump

    6.5 Disassemble the Pump CAUTION: • Avoid injury. Worn pump components can have sharp edges. Wear appropriate gloves while handling these parts. 6.5 Disassemble the Pump WARNING: • Failure to disconnect and lock out driver power may result in serious physical injury or death.
  • Page 59 6.5 Disassemble the Pump Figure 54: Disassembly Remove frame foot hold-down bolts. Remove bolts which hold frame adapter to casing. Adjust sling tension to support back pull-out assembly. Slide the back pull-out assembly from the casing. The Model 3175 has jacking bolts to assist disas- sembly.
  • Page 60 6.5 Disassemble the Pump 1. Impeller puller stud - Mach. from std 1" H.H.M bolt 5. 13/16 ± 0 to 1/32 2. 1-1/2 width across flats 6. Impeller 3. 1"112 R.H. threads 7. Shaft 4. 1/16 x 45° chamfer Figure 56: Impeller Puller Stud Thread the impeller puller stud into the end of the impeller.
  • Page 61 6.5 Disassemble the Pump If the pump has a packed stuffing box, remove packing and lantern ring from the stuffing box cover. If the pump has a mechanical seal, the rotary portion of seal will slide off with the sleeve. Do not damage seal faces.
  • Page 62 6.5 Disassemble the Pump Figure 59: Bearing housing bolt removal 22. Slide the complete shaft assembly from back end of bearing frame. This includes the shaft, both bearings (radial and thrust), and bearing housing. Do not lose or damage bearing housing O-ring. Figure 60: Shaft removal 23.

  • Page 63: Inspection And Overhaul

    6.6 Inspection and Overhaul 25. Tap the oil seal from the coupling end bearing end cover if replacement of seal is required. Refer to6.6 Inspection and Overhaul on page 61 for replacement sizes. 26. Slide the bearing housing off shaft. 27.

  • Page 64: Reassemble The Pump

    6.7 Reassemble the Pump foreign matter or burrs. The fit of the key in the keyway should also be checked to see that it is not caus- ing binding. The key should have a sliding fit on the sides and should have clearance at the top. Sleeve surface in stuffing box must be smooth and free of grooves.
  • Page 65 6.7 Reassemble the Pump WARNING: Lifting and handling heavy equipment poses a crush hazard. Use caution during lifting and handling and wear appropriate Personal Protective Equipment (PPE, such as steel-toed shoes, gloves, etc.) at all times. Seek assistance if necessary. Oil bearing seat on coupling end of shaft.
  • Page 66 6.7 Reassemble the Pump 1. O-ring Figure 63: Bearing housing O-ring Tap oil seal into the bearing end cover (inboard). 10. Slide gasket and inboard bearing end cover over shaft and bolt to bearing frame. Slide deflector on shaft with flat side in until it rests against the bearing frame. 12.
  • Page 67 6.7 Reassemble the Pump Figure 65: Bearing frame to bearing adapter 15. To install shaft sleeve and stuffing box cover: On units with a packed stuffing box, slide shaft sleeve with O-ring in place on the shaft. Tap stuffing box bushing into place by using a sleeve. Check sleeve O.D. and bushing I.D. so it meets requirements of 6.6 Inspection and Overhaul on page 61.
  • Page 68 6.7 Reassemble the Pump Figure 66: Stuffing box cover-to-casing gasket 18. Lubricate shaft keyway and insert impeller key in shaft and shaft sleeve. Lubricate shaft and slide impeller on shaft as far as possible. Pull impeller on shaft the remainder of distance with impeller screw.

  • Page 69: Set The Mechanical Seals

    6.8 Set the Mechanical Seals Table 6: Frame Adapter to Casing Bolts Torque Specifications Casing Size Torque, N-m | ft-lbs 12 inch 91 | 67 14 inch 244 | 180 18 inch 201 | 148 22 inch 233 | 172 28 inch 499 | 368 23.

  • Page 70: Stuffing Box

    6.9 Stuffing Box 1. Shaft 2. Sleeve 3. Scribe 4. Stuffing box Figure 68: Shaft sleeve Unbolt and remove the stuffing box cover. Remove sleeve. Lightly lubricate the rotary portion of the seal and slide onto the sleeve. Compress the rotary to the correct "working length". Refer to the seal manufacturer's drawing for correct dimensions.
  • Page 71 6.9 Stuffing Box 1. Out 2. In 3. For paper stock service 4. For process and evaporator service Figure 69: Stuffing box 3175 Installation, Operation and Maintenance Instructions...

  • Page 72: Troubleshooting

    7 Troubleshooting 7 Troubleshooting 7.1 Troubleshooting Checklist No liquid delivered Pump not primed - casing and suction pipe not completely filled with liquid. Speed too low. Discharge head too high. Check system head (particularly friction loss). Suction lift too high (suction pipe may be too small or long, causing excessive friction loss).
  • Page 73 7.1 Troubleshooting Checklist Wrong direction of rotation or impeller installed backwards. Be sure pressure gauge is in correct place on discharge nozzle or discharge pipe. Pump works a while and then quits Leaky suction line. Stuffing box packing worn - or liquid seal plugged - allowing leakage of air into pump cas- ing.
  • Page 74 7.1 Troubleshooting Checklist Improper lubrication. Excessive vibration. Bent shaft. Rotating element binds. When directly connected to electric motors, check whether motor wiring is correct and receives full voltage. When directly connected to steam turbines, make sure that turbine receives full steam pres- sure.

  • Page 75: Parts Listings And Cross-Sectionals

    8 Parts Listings and Cross-Sectionals 8 Parts Listings and Cross-Sectionals 8.1 Spare Parts To ensure against possible long and costly "downtime" periods, especially on critical services, it is advis- able to have spare parts on hand. The most desirable parts to have on hand are the following: Horizontally Split Case Pumps "Rotating element".

  • Page 76: Instructions For Ordering Spare Parts

    8.2 Instructions for Ordering Spare Parts Shaft sleeve (if any). Ball bearings - one of each. Shaft nut (if any). Bearing locknut and washer (if any). 8.2 Instructions for Ordering Spare Parts Repair orders will be handled with the minimum of delay if the following directions are followed: Give Model No., size of the pump and serial number.
  • Page 77 8.3 Parts List Group S Group M Group L Max liquid temp. grease lube H.P. per 100RPM 9.52 23.8 63.5 At impeller 1-7/8 2-3/4 Under shaft 5/16 sleeve 2-1/2 3-5/16 At coupling 1-7/8 2-3/8 Between 3-1/8 bearings Thru stuff- ing box Coupling MRC 7313 DB or MRC 7222 P.D.B or equal...
  • Page 78 8.3 Parts List Figure 70: Sectional View and Parts LIst 3175 Installation, Operation and Maintenance Instructions...
  • Page 79 8.3 Parts List Table 8: Materials of Construction Material Cu % Sn % Ph % Zn % NI % 1102 84-86 1103 1.75 0.75 1106 0.10-0.15 1000 - Cast Iron - conforms to ASTM A-278 Class 25 1003 - Cast Iron - conforms to ASTM A-278 Class 30 303 - Designates AISI Type 303 stainless steel 316 - Designates AISI Type 316 stainless steel (wrought) or ASTM A-296 Grade CF-8M and ACI-CF-8M (cast)
  • Page 80 8.3 Parts List Material Group S Group M Group L Part Name Eye bolt Steel Bearing lock- Steel nut w/lock- washer Bearing end 1000 cover, in- board Ball bearing, Steel inboard Suction piece 1000 11 C C C D D D D E E F Suction side- 1000 11 D E F...
  • Page 81 8.3 Parts List Material Group S Group M Group L Part Name 357A 4 Hex nut, sideplate AISI 303 stud Pipe plug, casing drain Gasket, .006 white manilla pa- bearing end cover, in- board 360A 1 Gasket, .006 white manilla pa- bearing end cover, cou- pling end...
  • Page 82 8.3 Parts List Material Group S Group M Group L Part Name 370H 2 H.H.M. bolt, adapter to Steel S.B. cover 370J 6 H.H.M. bolt, bearing end cover to Steel housing - coupling end 370K 6 H.H.M. bolt, bearing end cover to Steel frame in-...

  • Page 83: Pump Selection Chart

    8.4 Pump Selection Chart Pump Size Curve Pump Casing Material Acceptable Minimum Standard ANSI Mating Flanges and Fittings Discharge Suction 6 x 8-18 6 x 8-22 8 x 10-14 8 x 10-18 8 x 10-18H 8 x 10-22 10 x 12-18 10 x 12-22 316 Stainless steel 150 PSI flat face steel...
  • Page 84 8.4 Pump Selection Chart Model Descri- No. of Max. Ca- Max Head Type of Class of Number bed in Sizes and pacity Feet Temp. °F Working Impeller Construc- Bulletin Ranges G.P.M. Pressure tion Pump Type 3706 725.2 Open Small 1" glassed 3708 725.2...
  • Page 85 8.4 Pump Selection Chart Model Descri- No. of Max. Ca- Max Head Type of Class of Number bed in Sizes and pacity Feet Temp. °F Working Impeller Construc- Bulletin Ranges G.P.M. Pressure tion Pump Type Close- Coupled 3189 Sin- 720.4 3200 Open gle Stg,...
  • Page 86 8.4 Pump Selection Chart Class Materials of Construction Ductile iron (ASTM A395) Ni-Resist (Type 2) (ASTM A436) Carbon steel (ASTM A216 Grade WCA & WCB) 11-13% chrome stainnless (ACI CA15) 316 stainless (ACI CF8M) Gould A LOV 20 (ACI CN 7 MCU) Other special sand cast machinable alloys such as low, medium and high carbon steels, ACI CF 8C (347) 316 ELC, monel, nickel.
  • Page 87 Visit our website for the latest version of this document and more information: www.gouldspumps.com ITT Goulds Pumps, Inc. 240 Fall Street Seneca Falls, NY 13148 Form IOM.3175.en-US.2019-12 ©2019 ITT Inc. The original instruction is in English. All non-English instructions are translations of the original instruction.
