PCI-DIO24 User's Guide

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products (with
the C37FF-x or C37FFS-x cable)
Pin
Signal Name
IRQ INPUT
1
2
IRQ ENABLE
3
Port B7
Port B6
4
5
Port B5
6
Port B4
Port B3
7
8
Port B2
9
Port B1
10
Port B0
11
GND
12
OPEN
13
GND
14
-12V
15
GND
16
+12V
17
GND
18
+5V
19
GND
Table 4. Board connector, cables, and accessory equipment
37-pin D-type
C37FF-x unshielded ribbon cable. x = length in feet.
C37FFS-x cable shielded round cable. x = length in feet.
SCB-37
CIO-MINI37
CIO-MINI37-VERT
CIO-ERB08
CIO-SERB08
CIO-ERB24
CIO-SPADE50
SSR-RACK08
SSR-RACK24
Table 5. Connector pin out
Pin
Signal Name
20
+5V
21
GND
22
Port C7
23
Port C6
24
Port C5
25
Port C4
26
Port C3
27
Port C2
28
Port C1
29
Port C0
30
Port A7
31
Port A6
32
Port A5
33
Port A4
34
Port A3
35
Port A2
36
Port A1
37
Port A0
16
Specifications
