PCI-CTR05 User's Guide
Parameter
Input low voltage
Input high voltage
Output low voltage @ IIl=3.2 mA
Output high voltage @ IIH= -200 uA
Crystal oscillator frequency
Frequency accuracy

Power consumption

+5 V
+5 V available at connector

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions
Form factor

Main connector and pin out

The J1 connector is compatible with the CIO-CTR05 and the CIO-CTR10.
Connector type
Compatible cables
Compatible accessory products
Conditions
-0.5 V min, 0.8V max
2.2 V min, Vcc max
0.4 V max
2.4 V min
10 MHz
50 ppm
Table 4-4. Power consumption specifications
307 mA typical, 549 mA max. Does not include power consumed
through the I/O connector.
1 A max
Table 5. Environmental specifications
0 to 55 °C
-20 to 70 °C
0 to 90% non-condensing
Table 4-6. Mechanical specifications
132.3 mm (L) x 106.7 mm (W) x 11.65 mm (H)
Universal PCI keying. Compatible with either 3.3 V or 5 V PCI
signaling environments.
Table 4-7. Main connector specifications
37 pin shielded D-type, right angle
C37FF-x, unshielded ribbon cable
C37FFS-x, shielded round cable
CIO-MINI37
CIO-MINI37-VERT
CIO-TERMINAL
SCB-37
4-3
Specifications
