View

The View menu allows you to move quickly between interfaces without using the icon
buttons on the App Mode toolbar. It also allows you to access the Bar Code Dialog.
Bar Code Dialog
In the Bar Code Dialog you can create symbols by typing the text you wish to encode. This is a
useful tool for creating configuration symbols, allowing you to configure your reader by reading
the symbols you create.
Choose a spatial
orientation for the
new symbol.
MS-4Xi Imager User's Manual
The symbol you create
will be displayed in the
field at the bottom of the
Bar Code Dialog.
Using ESP
Drag specific configuration
values from the control tree
directly into this field to
encode new symbols.
Create a caption
for the symbol
that matches the
encoded data, or
write your own
caption.
