Serial Configuration Commands
Appendix C — Serial Configuration Commands
Note: For a list of utility commands such as read rate requests, device control options, and
imager status requests, see
Communications
Host Port Connections
Ethernet
Ethernet TCP Ports
Host Port Protocol
Preamble
Postamble
Response Timeout
LRC
ACK/NAK Options
Polling Mode Options
Calibration
Calibration Options
Autocalibrate
Read Cycle
Trigger Mode/Filter Duration
Serial Trigger Character
External Trigger State
End of Read Cycle
Minimum Good Reads
Multisymbol
Start Trigger Character
Stop Trigger Character
Capture Mode
Capture Timing
Image Storage
Image Processing Timeout
Symbologies
Narrow Margins/Symbology ID
Background Color
Composite
Aztec Code
A-14
Serial Utility Commands.
<K100,baud rate,parity,stop bits,data bits>
<K126,status,IP address,subnet,gateway,IP address mode>
<K127,TCP Port 1,TCP Port 2>
<K140,protocol,address>
<K141,status,preamble characters>
<K142,status,postamble characters>
<K143,response timeout>
<K145,status>
<K147,RES,REQ,STX,ETX,ACK,NAK>
<K148,RES,REQ,STX,ETX,ACK,NAK>
<K529,gain,shutter speed,symbol type,WOI framing, WOI margin,
line scan height>
<@CAL>
<K200,trigger mode,leading edge trigger filter,trailing edge trigger
filter>
<K201,serial trigger character>
<K202,external trigger state>
<K220,end of read cycle,read cycle timeout>
<K221,minimum good reads>
<K222,number of symbols,multisymbol separator>
<K229,start character>
<K230,stop character>
<K241,capture mode,number of captures,rapid capture mode>
<K242,time before first capture,time between first and second
captures,,,,,,,,time between seventh and eighth captures>
<K244,image storage type,image store mode>
<K245,image processing timeout>
<K450,narrow margin status,symbology identifier status>
<K451,background color>
<K453,symbology status,separator status,separator>
<K458,status>
