Quick Start - Microscan MS-4Xi User Manual

Contents
Step 1 Check Hardware................................................................................................................ 1-2
Step 2 Connect the System .......................................................................................................... 1-3
Step 3 Position Imager and Symbol.............................................................................................. 1-4
Step 4 Install ESP ......................................................................................................................... 1-5
Step 5 Select Model...................................................................................................................... 1-6
Step 6 Connect ............................................................................................................................. 1-7
Step 7 Locate the Symbol in the Field of View ............................................................................. 1-8
Step 8 Calibrate ......................................................................................................................... 1-10
Step 9 Test Read Rate .............................................................................................................. 1-11
Step 10 Configure the Imager in ESP........................................................................................ 1-12
Step 11 Save Configuration in ESP ........................................................................................... 1-13
This section is designed to get your MS-4Xi up and running quickly, using the EZ button or
ESP (Easy Setup Program). Following these steps will allow you to get a sense of the
imager's capabilities and to test sample symbols.
Detailed setup information for installing the imager into your actual application can be
found in the subsequent sections.
MS-4Xi Imager User's Manual

1 Quick Start

1-1
