EZ Button Modes

EZ Button Modes

Usage: Useful for performing multiple, repetitive tasks at the work site.
Definition: Allows the user to program each of the EZ button's 4 positions from a selection
of 8 modes.
Serial Cmd: <K771,position 1 mode,position 2 mode,position 3 mode,position 4 mode>
Options: 0 = Disabled
Single Beep
0 = Disabled
1 = Read Rate
2 = Calibrate
3 = Save for Power-On
4 = Unused
5 = Load New Master
6 = Unused
7 = Target System
8 = Unused
9 = Bar Code Config.
Disabled
When set to disabled, the associated button position will have no function associated with
it, and the position will be skipped over.
Read Rate
Read Rate will be initiated when the associated button position is selected. Read Rate will
perform decodes/second and is the same as sending a
Read Rate Mode quickly press and release the EZ button.
Calibrate
Calibration will be initiated when the associated button position is selected. To abort calibration,
quickly press and release the EZ button.
Save for Power-On
All imager settings will be saved to non-volatile memory to be recalled on power-on
whenever the associated button position is selected. This is the same as sending a
from the terminal.
Load New Master
Functions in the same way as new master pin input whenever the associated button
position is selected. The new master pin's Consecutive Decode requirement holds true
for this function.
7-18
1 = Enabled
Two Beeps
0 = Disabled
1 = Read Rate
2 = Calibrate
3 = Save for Power-On
4 = Unused
5 = Load New Master
6 = Unused
7 = Target System
8 = Unused
9 = Bar Code Config.
Three Beeps
0 = Disabled
1 = Read Rate
2 = Calibrate
3 = Save for Power-On
4 = Unused
5 = Load New Master
6 = Unused
7 = Target System
8 = Unused
9 = Bar Code Config.
<C> from the terminal. To exit
MS-4Xi Imager User's Manual
Four Beeps
0 = Disabled
1 = Read Rate
2 = Calibrate
3 = Save for Power-On
4 = Unused
5 = Load New Master
6 = Unused
7 = Target System
8 = Unused
9 = Bar Code Config.
<Z>
