I/O Parameters Serial Commands

Power On/Reset Counts
Time Since Reset
Service Message
Serial Verification
Beeper
Quality Output
Symbol Data Output
No Read Message
Frame Information
LED Configuration
Image Output
Target/Flood LEDs
EZ Trax Output
Database Identifier Output
EZ Button
EZ Button Modes
Trend Analysis Output 1
Trend Analysis Output 2
Trend Analysis Output 3
Diagnostic Output 1
Diagnostic Output 2
Diagnostic Output 3
ISO/IEC 16022 Symbol Quality Output 1
ISO/IEC 16022 Symbol Quality Output 2
ISO/IEC 16022 Symbol Quality Output 3
Configurable Output 1
Configurable Output 2
Configurable Output 3
MS-4Xi Imager User's Manual
<K406,power-on,resets,power-on saves,power-on flash saves>
<K407,hours,minutes>
<K409,status,service message,threshold,resolution>
<K701,serial command echo status,serial command beep status,control/hex
output>
<K702,status>
<K704,quality output separator,decodes per trigger status>
<K705,symbol data output status,when to output>
<K714,status,message>
<K734,output frame number,output coordinates>
<K737,LED mode,ISO/IEC 16022 grade>
<K739,image output mode,communication port,file format,JPEG quality>
<K750,green flash LED status,target pattern LED status,green flash
duration>
<K757,comm port,image mode,image format,JPEG quality,object info
output,grade output>
<K759,status,separator>
<K770,global status,default on power-on,load Configuration Database,
save for power-on>
<K771,single beep,two beeps,three beeps,four beeps>
<K780,trend analysis mode,trigger evaluation period,number to output
on,decodes per trigger threshold>
<K781,trend analysis mode,trigger evaluation period,number to output
on,decodes per trigger threshold>
<K782,trend analysis mode,trigger evaluation period,number to output
on,decodes per trigger threshold>
<K790,unused 1,service unit>
<K791,unused 1,service unit>
<K792,unused 1,service unit>
<K800,output on symbol contrast,symbol contrast threshold,output on
print growth,print growth threshold,output on axial non-uniformity,axial
non-uniformity threshold,output on UEC,UEC threshold>
<K801,output on symbol contrast,symbol contrast threshold,output on
print growth,print growth threshold,output on axial non-uniformity,axial
non-uniformity threshold,output on UEC,UEC threshold>
<K802,output on symbol contrast,symbol contrast threshold,output on
print growth,print growth threshold,output on axial non-uniformity,axial
non-uniformity threshold,output on UEC,UEC threshold>
<K810,output on,output state,pulse width,output mode>
<K811,output on,output state,pulse width,output mode>
<K812,output on,output state,pulse width,output mode>
I/O Parameters
7-3
