Terminal Window

Terminal Window

Click this button to display the Terminal view.
The following view will appear:
Copy, paste, save
Clear screen
Macros listed
on this bar
The Terminal screen allows you to send serial commands to the imager by using Macros,
by copying and pasting, or by typing commands in the Send text field.
The Terminal screen also displays symbol data or information from the imager.
You can also right-click on the Terminal screen to bring up a menu of further options.
12-2
Type text here to
find matching text
in the Terminal
window.
Click on Macros arrow to Add Macro,
Remove Macro, or Edit Macro.
Terminal Type serial
screen commands
here.
Click on desired
Macro to run.
