Registration (printer)

Print registration makes sure the printing is properly aligned on the page.
The settings available are:
Description
Top Margin
Bottom Margin
Left Margin
Right Margin
REGISTRATION
Top Margin
Bottom Margin
Left Margin
Right Margin
Quick Test
Submit
Value
-25 to +25
Each increment causes
approximately 4 pels shift (at
600 dpi).
-20 to +20
Each increment causes
approximately 0.55 mm shift in the
bottom margin.
-25 to +25
-10 to +10
0
0
0
0
Back
Direction of change
A positive change moves the image down the
page and increases the top margin. A negative
change moves the image up and decreases the
top margin.
A positive change compresses the image so it
appears to move down the page, and a negative
change moves the image up.
A positive change moves the image right, and a
negative change moves the image left. No
compression occurs.
A positive change moves the image left, and a
negative change moves the image right.
