Setting up
fax ports for
ActiveFax
DO THIS SECTION?
TURNKEY
SYSTEM
Voice mail only
Voice mail with LAN admin
Unified, one Exchange server
Unified, existing Exchange site
COMPONENT
SYSTEM
Voice mail only
Voice mail with LAN admin
Unified, one Exchange server
Unified, existing Exchange site
ACTIVEFAX SERVER
If you installed ActiveFax, run the FAX Monitor program to:
Set whether a fax port sends faxes, receives faxes, or both
sends and receives faxes.
Enter settings for routing inbound faxes.
The FAX Monitor contains information about the fax ports on the
server that ActiveFax is installed on; the information was auto-
matically detected during the ActiveFax installation. The infor-
YES NO
mation is displayed in the FAX Monitor window, shown below,
see
page
and in its Setup dialog box.
80
Each square at the bottom of the FAX Monitor window repre-
sents a fax port. Colored squares indicate fax ports that are
available for use with ActiveFax.
The number of fax ports available to ActiveFax is specified on the
Unity system key (or on the ActiveFax system key if ActiveFax is
on a separate server). If the number on the key is less than the
total number of fax ports on the installed fax boards, ActiveFax
disables the extra ports. A red "X" in a FAX Monitor square
80
means that ActiveFax has disabled the corresponding fax port.
CHAPTER 3: Installing a Unity system
Continued
75
