Dialogic D/41D
voice board
Continued
118
UNITY INSTALLATION GUIDE
Software settings
During Unity Setup, do the following procedure when the Dia-
logic Board Configuration dialog box appears.
To enter Dialogic settings during Unity Setup
a Change the value of "Number of boards" to the number of
Dialogic D/41D boards in the server.
b Change the value of "IRQ" to "5."
c In the Board Addresses list, select one address for each
D/41D board in the server:
Turnkey system
tive values.
Component system
during the procedure "To find and reserve memory
addresses and an IRQ (ISA boards in a component system
only)," on page 35.
d Click "OK" to continue.
e Return to the procedure that you were doing when the Dia-
logic Board Configuration dialog box appeared.
Start with "0xD0000" and select consecu-
Select the addresses that you reserved
