Hardware settings
Do the following procedure as you install fax boards.
To set switch block SW1
The switch block SW1 settings determine the fax ports' I/O
addresses.
The CPi/200 board contains two fax ports. Depending on the
configuration of the Unity server, you can install up to two
CPi/200 boards.
Set the SW1 switches on each board as shown below.
First board
Ports 0–1
First board
Ports 4–5
LED status indicators
There are two LED status indicators for each fax port. The fol-
lowing table describes the meaning of the status indicators.
Color
Lit
Green
Port is off hook
Amber
Board is
operational
APPPENDIX A: Voice and fax boards
SW1
On
Off
1 2 3
On
Off
1 2 3
Unlit
Port is on hook
Board is not
operational
Blinking
---
Board configuration
problem
145
