FUEL SYSTEM

3.2. FUEL PUMP

3.2.1.

REMOVING THE FUEL PUMP ASSEMBLY

•
Completely remove the fuel tank.
IMPORTANT Position the tank on a clean surface with the
pump unit uppermost.
•
Loosen and remove the eight screws (1).
IMPORTANT To refit, fasten all screws (1) by hand in their
holes and tighten in a cross pattern.
WARNING
When removing the pump assembly make sure
not to damage the fuel hoses and level sensor.
•
Remove the entire fuel pump assembly.
3 - 12
RSV 1000 R - RSV 1000 R FACTORY
