2.1.7. ARRANGEMENT OF THE INSTRU-
MENTS/CONTROLS
Key:
1. Clutch lever
2. Ignition/steering lock switch (
3. Instruments and indicators
4. Front brake lever
5. Throttle twistgrip
6. High beam flasher (
7. Light dimmer switch (
8. Direction indicator switch (
9. Horn button ( )
10. Starter button ( )
11. Engine kill switch (
Key:
1. Rev counter
2. Red line light
3. Green direction indicator light (
4. Blue high beam light (
5. Amber "stand down" light ( )
6. Amber low fuel light ( )
7. Red immobilizer light (
is fitted)
8. Green neutral light (N)
9. Multifunction digital display (coolant temperature - clock
- battery voltage - lap timer - engine oil pressure
diagnostics ( )
10. Red general warning light (
11. Multifunction computer
(+, Trip V, -)
- - )
)/LAP button (multifunction)
- )
)
)
)
)
) (where immobilizer system
)
programming
GENERAL TECHNICAL INFORMATION
buttons
2 - 25
