APRILIA RSV 1000 R FACTORY Workshop Manual page 59

GENERAL TECHNICAL INFORMATION
RSV 1000 R - RSV 1000 R FACTORY
CURRENT/MAX/AVERAGE SPEED AND BATTERY
VOLTAGE DISPLAY
IMPORTANT The average/max speed and battery voltage
are only displayed with the vehicle stationary. Only the cur-
rent speed is displayed when the vehicle is being driven.
When the ignition key is turned to " " the current speed is
displayed. To display the max speed (V max), average
speed (AVS) and battery voltage, press the + key.
To reset the max speed (V max) and average speed (AVS),
press the – key for at least 3 seconds while the values are
being displayed.
IMPORTANT The max and average speed readings refer to
the period since they were last reset.
The battery voltage reading (V) is not modifiable and gives
information on the operating condition of the battery.
The recharger circuit is operating correctly if the battery volt-
age reads 13 to 15 V with the headlamp set to low beam and
the engine running at 4000 rpm.
Instruments lighting adjustment: the dashboard backlighting
can be adjusted to three levels (30%, 70%, 100%); this is
done by pressing the – key during the first 5 seconds after
the ignition key has been turned to " ".
TOTAL AND PARTIAL (TRIP 1 / 2) ODOMETER DIS-
PLAYS
When the ignition key is turned to " " the odometer is dis-
played. To display the partial odometer readings (TRIP 1 / 2),
press the TRIP/V key.
2 - 27
