Ethernet Specifications

The following table describes the Ethernet specifications for the Hitachi
Simple Modular Storage.
Works with switches that comply to the
following standards:
Cable Type
Figure B-2: RJ-45 Jack on the Hitachi Simple Modular Storage 100
B–6
Table B-8: Ethernet Specifications
Parameter
Figure B-1: RJ-45 Jack on Ethernet Cable
Hitachi Simple Modular Storage 100 User's Guide
Specification
IEEE 802.1D STP
IEEE 802.1w RSTP
IEEE 802.3 CSMA/CD
IEEE 802.3u Fast Ethernet
IEEE 802.3z 1000BaseX
IEEE 802.1Q Virtual LANs
IEEE 802.3ad Dynamic LACP
RFC 768 UDP
RFC 783 TFTP
RFC 791 IP
RFC 793 TCP
RFC 1157 SNMP v1
RFC 1213 MIB II
RFC 1757 RMON
RFC 1901 SNMP v2
RJ-45 1000BASE-TX UTP or STP (STP is
recommended)
