Front Panel Components

Identifying Hardware
In This Chapter
This chapter describes the hardware components on your Hitachi
Simple Modular Storage 100 array. This chapter covers the
following key topics:
Front Panel Components
Back Panel Components
Top Components
Figure 2-1 shows the hardware components on the front panel of
your Hitachi Simple Modular Storage 100.
• Drive Slot
(behind bezel)
Figure 2-1: Front Panel Components
•

Identifying Hardware Components

Hitachi Simple Modular Storage 100 User's Guide
Components
Power LED
(green)
Ready LED
(green)
Warning LED
(orange)
2
Drive Slot
(behind bezel)
Alarm LED
(red)
2–1
