Warning LED

The orange Warning LED shows when your Hitachi Simple Modular Storage
100 is operating normally, has encountered a nonfatal error, and is
upgrading firmware.
LED Status
OFF
ON or Slow
Blink
Fast Blink

Back Panel Components

Figure 2-2
controller Hitachi Simple Modular Storage 100. Components associated with
CTL0 are indicated with blue callouts in the following figure, while
components associated with CTL1 are indicated with red callouts. If your
Hitachi Simple Modular Storage 100 has a single controller, ignore the
components for CTRL 1.
NOTE: If your Hitachi Simple Modular Storage 100 has a single controller,
ignore the components for CTL1.
•
Auto Migration Port
iSCSI Data Ports
CTL1
CTL0
MAIN Switch
Maintenance Port
Management Port
Table 2-4: Warning LED
Normal operation
Nonfatal error. Array can remain operating.
Flash is being updated with new firmware (do not turn off the array).
shows the key hardware components on the back panel of a 2-
Fan Power
Receptacle
Figure 2-2: Key Back Panel Components
Identifying Hardware Components
Hitachi Simple Modular Storage 100 User's Guide
Description
Management Port
Maintenance Port
Power
Receptacle
iSCSI Data Ports
Auto Migration Port
Fan
2–3
