Specifying Mode Parameters

After you run the Storage Navigator Modular 2 wizards, use Storage
Navigator Modular 2 to set mode parameters. The selections you make will
be based on your host's operating system and clustering configuration.
To access this page, use the following procedure.
1. If the Arrays pane appears next to the Explorer pane, skip to the next
step. Otherwise:
a. In the Explorer pane, click Resources > Arrays.
b. In the Arrays area, check an array to be initialized.
c. Click Show & Configure Array.
2. In the Arrays pane, select Groups > iSCSI Targets.
3. Under the iSCSI Target column, check an iSCSI target. Then click Edit
Target.
4. When the Edit iSCSI Target window appears, click on the Options tab
and make the following selections (see
a. Platform — select your host's operating system. If your host's
operating system is not shown, select not specified.
b. Middleware — select Not specified for all operating systems.
c. Common Setting — select Standard Mode for all operating
systems.
d. Additional Settings — select None for all operating systems.
For This Operating
System
Asianux
Red Hat Linux
Microsoft Windows
2003
Microsoft Windows XP Windows
Microsoft Windows
Vista
Solaris
SuSE Linux Enterprise
Server (SLES)
VMware
Table 3-4: Mode Parameters
Select This ...This Middleware
Platform...
Linux Not specified (none)
Linux Not specified (none)
Windows Not specified (none)
Not specified (none)
Windows Not specified (none)
Solaris Not specified (none)
Linux Not specified (none)
Not specified Not specified (none)
Installing Your Array
Hitachi Simple Modular Storage 100 User's Guide
Table 3-4):
...and These Mode Settings
Common
Setting...
Setting
Standard Mode
Standard Mode
Standard Mode
Standard Mode
Standard Mode
Standard Mode
Standard Mode
Standard Mode
Additional
Settings
None
None
None
None
None
None
None
None
3–21
